Running a device server, the following settings can be applied:
Parameter
Physical protocol
Baud rate
Data bits
Parity
Stop bits
Software flow control
NB3710 User Manual 3.8
Figure 5.18.: Serial Port Settings
Serial Settings
Selects the desired physical protocol on the serial port
Specifies the baud rate run on the serial port
Specifies the number of data bits contained in each frame
Specifies the parity used for every frame that is transmitted
or received
Specifies the number of stop bits used to indicate the end
of a frame
Defines the software flow control for the serial port, XOFF
will send a stop, XON a start character to the other end to
control the rate of any incoming data
