5.4.2. Extended Routing

Extended routes can be used to perform policy-based routing, they generally precede
static routes.
In contrast to statis routes, extended routes can be made up, not only of a destination
address/netmask, but also a source address/netmask, incoming interface and the type
of service (TOS) of packets.
Parameter
Source address
Source netmask
Destination address
Destination netmask
Incoming interface
NB3710 User Manual 3.8
Figure 5.21.: Extended Routing
Extended Route Configuration
The source address of a packet
The source address of a packet
The destination address of a packet
The destination address of a packet
The interface on which the packet enters the system
