Please note that the specified rules are processed by order, that means, traversing the
list from top to bottom until a matching rule is found. If there is no matching rule
found, the packet will pass as is.
Parameter
Description
Incoming interface
Target address
Protocol
Ports
Redirect to
Redirect port
NAPT Outbound Rules
Outbound rules will modify the source section of IP packets and can be used to establish
1:1 NAT mappings but also to redirect packets to a specific service.
Parameter
Description
Incoming interface
Source address
Protocol
Ports
Rewrite source address
Rewrite source port
NB3710 User Manual 3.8
Inbound NAPT Rules
A meaningful description of this rule
The interface from which matching packets are received
The destination address of matching packets (optional)
The used protocol of matching packets
The used UDP/TCP port of matching packets
The address to which matching packets shall be redirected
The port to which matching packets will be redirected
Outbound NAPT Rules
A meaningful description of this rule
The outgoing interface on which matching packets are leav-
ing the router
The source address of matching packets (optional)
The used protocol of matching packets
The used UDP/TCP port of matching packets
The address to which the source address of matching packets
shall be rewritten
The port to which the source port of matching packets shall
be rewritten
