Advantech IPMI-2000 Startup Manual

IPMI-2000
IPMI Module, AST2600 Chipset
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. IPMI-2000 module x 1
2. Startup manual x 1
3. Warranty Card x 1
4. VGA cable x 1
5. Post x 3
6. Screw x 6
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the IPMI-2000 Series.
Part No. 2042200000
Printed in China
P/N: 2042200000
P/N: 2190000902
P/N: 1700020950-01
P/N: 1910003770-01
P/N: 19350304A0
1st Edition
August 2021
Specifications
General Features
• Out of band (OS independent)
• User management
• Remote control
• System health
• Maintenance
ASMB Support List
ASMB-587G2-00A1
ASMB-587G4-00A1
Note: For more ASMB support list, please visit our website.
Mechanical and Environmental
• Dimensions: 218 mm x 122 mm
• Power supply type: 5 VSB
• Power requirements: 5 VSB @ 55mA
• Operating temperature: 0 ~ 60° C
• Operating humidity: 60° C @ 85% RH, Non-Condensing
• Storage temperature: -40 ~ 85° C
• Storage humidity: 60° C @ 95% RH, Non-Condensing
• Weight: 20 g
Connectors
There are three connectors on the module and one of them
is used to connect with ASMB. The below table lists the
functions of these connectors.
Connectors
Label Function
BMC_CN1 IPMI connector
VGA1 VGA1 connector
BMC_SPI1 BMC SPI ROM
IPMI-2000 Startup Manual 1
