Advantech MIC-75M20-00B Startup Manual

MIC-75M20-00B
PCIE Expansion Module for MIC-7 Series Embedded
System
Startup Manual
Packing List
Before you begin installing your card, please make sure
that the following items have been shipped:
1. MIC-75M20-00B i-Module x1
2. MIC-75M20-00B Startup Manual x1 P/N: 20015M2020
3. Warranty Card
4. Card Clamp Pad x 2
5. Wallmount BKT (Left) x1
6. Wallmount BKT (Righ) x1
If any of these items are missing or damaged, please
contact your distributor or sales representative immediately.
Acrobat Reader is required to view any PDF file.
Note:
Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/default.
aspx
This manual is for the MIC-75M20-00B Rev. A1.
Part No. 20015M2020
Printed in China
P/N: MIC-75M20-00B1
P/N: 2190000902
P/N:1990024989T000
P/N: 1960070545N001
P/N: 1960070543T001
1st Edition
July 2018
Specifications
PCIe Slots
• One PCIe x16 socket
Note 1: PCIe x16 power consumes 35W.
• One PCIe x4 socket
Note 2: PCIe x4 supports 15W power consumption.
Note 3: MIC-75M20 does not support MIC-7300 series
systems.
Environment
• Operating Temperature:
-20 ~ 60° C with 0.7 m/sec air flow: with 1 x Industrial SSD
without PC expansion boards
0 ~ 45° C with 0.7 m/sec air flow: with 1 x 2.5" HDD
without PC expansion boards
• Storage Temperature: - 40 ~ 85° C (-40 ~185° F)
• Relative Humidity: 95% @ 40° C (non-condensing)
Mechanical
• i-Module Dimensions (H x W x D): 50 x 192 x 230 mm
• With MIC-7 series (H x W x D): 123 x 192 x 230 mm
Note: We suggest to add an optional system fan (P/N:
98R1750020E) if power consumption of add-on
card is more than 45W - for better thermal man-
agement.
