Product specification (Elite 3 ILDA)

Type of laser:
Guaranteed optical output:
Suitable for:
Control signal:
Scanning system:
Scan angle:
Safety:
Weight:
Package includes:
R | G | B [mw]:
Beam size [mm]:
Beam divergence:
Modulation:
Power requirements:
Consumption:
Operation temperature:
Ingress rating:
System features:
Laser safety features:
Notice:
Dimensions [cm]:
Elite ILDA series Operational Manual (Revision 2022-10)
full-colour, semiconductor diode laser system
> 3,100mW
small to medium indoor / outdoor laser shows and laser
graphic displays
ILDA - We recommend Pangolin FB3QS and QuickShow
30,000 points per second @ 8°
50°
fully complies with the latest EN 60825-1, and FDA
regulations
8 kg
Heavy duty flight case, power cord, 10m ILDA signal cable,
E-STOP box with 10m cable, set of 4 safety keys, 3-pin
interlock bypass plug, user guide.
610 | 800 | 1760
2 x 4
<1mrad [full angle]
Analog, 100kHz
100-230V/50Hz
max. 150W
10-40 °C
IP 20
All the adjustments such as power output of each colour,
X & Y axes invert, X & Y size and position, etc. Scanning
system protection, daisy chain of emergency STOP signal
for multiple system "one-hit" operation, internal fuse.
Keyed interlock, emission delay, magnetic interlock, scan-
fail safety, mechanical shutter, adjustable aperture masking
plate.
*Due to Advanced Optical Correction technology used
in our laser systems the optical power output of each
laser colour within the system may slightly differ from the
specification of respective laser module(s) installed.
This does not affect the total guaranteed power output.
Length: 238
Width: 246
Height: 175
