Caution – use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
This Laser Product is designated as Class 4 during all procedures of operation.
REMINDER: In the United States, this laser product may not be purchased, sold, rented, leased or loaned for
use unless the recipient possesses a valid Class 4 laser light show variance from the US FDA CDRH.

OPERATION

INSTRUCTIONS FOR POWERING ON THE LASER SYSTEM
1. Connect power cable and E-stop.
2. Connect the 3-pin Interlock cable between the E-stop box and projector, pull up the red mushroom switch
and turn on the key switch. Press the start button. Confirm secondary E-stop port has either the bypass
plug installed or a secondary interlock device attached.
3. Connect the DB25 ILDA cable(s) to the projector. Then connect to any software box (for example Pangolin
QuickShow FB3 or FB4 hardware), and then select the pattern on software. Notice; please choose "Allow
laser output" in software.
See the next page for demonstration photos.
