UNITY Lasers RAW 20 FB4 User Manual

Ip65
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
UNITY Lasers s.r.o. | Unity Lasers, LLC
Notice
AVOID EYE OR SKIN EXPOSURE
TO DIRECT OR SCATTERED LIGHT
CLASS 4 LASER PRODUCT
USER MANUAL
RAW 20 FB4 (IP65)
RAW 30 FB4 (IP65)
RAW 40 FB4 (IP65)
1265 Upsala Road, Suite 1165,
RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11)
Manufactured / Certified by
Unity Lasers s.r.o.
Odboraska, 23
831 02 Bratislava
Slovakia, Europe
UNITY Laser LLC
Sanford, FL 32771
Classified per IEC 60825-1: 2014
Complies with US FDA CDHR laser safety
standards 21 CFR 1040.10 & 1040.11
and Laser notice

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAW 20 FB4 and is the answer not in the manual?

Questions and answers

Related Manuals for UNITY Lasers RAW 20 FB4

Summary of Contents for UNITY Lasers RAW 20 FB4

  • Page 1 RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC USER MANUAL RAW 20 FB4 (IP65) RAW 30 FB4 (IP65) RAW 40 FB4 (IP65) Manufactured / Certified by Notice Unity Lasers s.r.o. Classified per IEC 60825-1: 2014...

  • Page 2: Table Of Contents

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC CONTENTS INTRODUCTION WHAT IS INCLUDED UNPACKING INSTRUCTIONS GENERAL INFORMATION SAFETY NOTES LASER AND SAFETY NOTES LASER EMISSION DATA LASER COMPLIANCE STATEMENT PRODUCT SAFETY LABEL LOCATION...

  • Page 3: Introduction

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC INTRODUCTION Thank you for purchasing this purchase. To optimize the performance of your laser, please read these operating instructions carefully and familiarize yourself with the basic operations of this system. These instructions contain important safety information regarding the use and maintenance of this system as well.

  • Page 4: Safety Notes

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC SAFETY NOTES WARNING! This projector is Class 4 laser product. It must never be used for audience-scanning applications. The output beam of the projector must always be at least 3 metres above the floor in the audience. See the Operating Instructions section for further information.

  • Page 5: Laser And Safety Notes

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC LASER AND SAFETY NOTES STOP AND READ ALL THE LASER SAFETY NOTES BELOW Laser Light is different from any other light sources with which you may be familiar. The light from this product can cause eye and skin injury if not set up and used properly.

  • Page 6: Laser Emission Data

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC LASER EMISSION DATA • Class 4 Laser Projector - Avoid Eye and Skin Exposure to Direct or Scattered Light! • This Laser Product is designated as Class 4 during all procedures of operation.

  • Page 7: Product Safety Label Location

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC PRODUCT SAFETY LABEL LOCATION RAW 20/30/40 FB4 (IP65) FRONT PANEL Hazard Warning Symbol 2. Exposure Label 3. Laser Light Warning Label TOP PANEL 4. Danger Label 5.

  • Page 8: Product Safety Labels

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC PRODUCT SAFETY LABELS Logotype Danger Label Hazard Warning Symbol Aperture Label Aircraft Warning Label Interlocked Housing Label...
  • Page 9 RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC Laser Light Warning Label Certification Label This product is in conformity with performance standards for laser products under 21 CFR Part 1040.10 and 1041.11 except with respect to those...

  • Page 10: Interlock Connection Diagram

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC INTERLOCK CONNECTION DIAGRAM...

  • Page 11: Instructions For Using E-Stop System

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC INSTRUCTIONS FOR USING E-STOP SYSTEM Connect the E-stop box to the 3-pin interlock connector on the rear of the laser projector using a 3-PIN XLR cable.

  • Page 12: Theory Of Operation

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC THEORY OF OPERATION “UNITY Laser projector” is supplied with “E-Stop Box” and “Remote Interlock Bypass” including one cable. If user doesn’t need additional “User E-Stop Switch”, “Remote Interlock Bypass” should be inserted into “Remote Interlock Connector”...

  • Page 13: Operation

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC Caution – use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. This Laser Product is designated as Class 4 during all procedures of operation.

  • Page 14: Safety Tests

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC SAFETY TESTS E-STOP FUNCTION • With the projector operating and projecting laser light, press the red E-stop switch. The projector must shut off immediately. •...

  • Page 15: Model Specification

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC PRODUCT SPECIFICATION (RAW 20 FB4 (IP65)) Product Name: Unity RAW 20 FB4 (IP65) Type Of Laser: Full-color, Semiconductor diode laser system Guaranteed Optical Output: >20W Arena sized venues (up to 20,000 people), outdoor shows.

  • Page 16: Product Specification (Raw 30 Fb4 (Ip65))

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC PRODUCT SPECIFICATION (RAW 30 FB4 (IP65)) Product Name: Unity RAW 30 FB4 (IP65) Type Of Laser: Full-color, Semiconductor diode laser system Guaranteed Optical Output: >30W Stadium sized venues (up to 30,000 people), large outdoor shows.

  • Page 17: Product Specification (Raw 40 Fb4 (Ip65))

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC PRODUCT SPECIFICATION (RAW 40 FB4 (IP65)) Product Name: Unity RAW 40 FB4 (IP65) Type Of Laser: Full-color, Semiconductor diode laser system Guaranteed Optical Output: >4t0W Stadium sized venues (over 30,000 people), large outdoor shows.

  • Page 18: Front & Rear Panel View (Raw 20/30/40 Fb4 (Ip65))

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC FRONT & REAR PANEL VIEW (RAW 20/30/40 FB4 (IP65)) Name Function Laser Aperture Laser output, do not look directly into this aperture. Aperture Masking Plate Can be moved up and down when two locklng bolts are loosened.

  • Page 19: Dimension Details (Raw 20/30/40 Fb4 (Ip65))

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC DIMENSION DETAILS (RAW 20/30/40 FB4 (IP65))

  • Page 20: Technical Information - Maintenance

    RAW 20/30/40 FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC TECHNICAL INFORMATION - MAINTENANCE GENERAL CLEANING INSTRUCTIONS - TO BE DONE BY USER Due to fog residue, smoke, and dust cleaning the external body of the projector should be carried out periodically to optimize light output.
