UNITY Lasers ELITE 10 PRO FB4 User Manual

Ip65
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
UNITY Lasers s.r.o. | Unity Lasers, LLC
ELITE 10 PRO FB4 (IP65)
ELITE 20 PRO FB4 (IP65)
ELITE 30 PRO FB4 (IP65)
ELITE 60 PRO FB4 (IP65)
ELITE 100 PRO FB4 (IP65)
Notice
AVOID EYE OR SKIN EXPOSURE
TO DIRECT OR SCATTERED LIGHT
CLASS 4 LASER PRODUCT
ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11)
USER MANUAL
Manufactured / Certified by
Unity Lasers s.r.o.
831 02 Bratislava
Slovakia, Europe
UNITY Laser LLC
1265 Upsala Road, Suite 1165,
Sanford, FL 32771
Odboraska, 23
Classified per IEC 60825-1: 2014
Complies with US FDA CDHR laser safety
standards 21 CFR 1040.10 & 1040.11
and Laser notice

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELITE 10 PRO FB4 and is the answer not in the manual?

Questions and answers

Related Manuals for UNITY Lasers ELITE 10 PRO FB4

Summary of Contents for UNITY Lasers ELITE 10 PRO FB4

  • Page 1 ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC USER MANUAL ELITE 10 PRO FB4 (IP65) ELITE 20 PRO FB4 (IP65) ELITE 30 PRO FB4 (IP65) ELITE 60 PRO FB4 (IP65) ELITE 100 PRO FB4 (IP65)

  • Page 2: Table Of Contents

    INTERLOCK RESET FUNCTION (REMOTE INTERLOCK BYPASS) MODEL SPECIFICATION • PRODUCT SPECIFICATION (ELITE 10 PRO FB4 (IP65)) • FRONT & REAR PANEL VIEW (ELITE 10 PRO FB4 (IP65)) • DIMENSION DETAILS (ELITE 10 PRO FB4 (IP65)) • PRODUCT SPECIFICATION (ELITE 20 PRO FB4 (IP65)) •...

  • Page 3: Introduction

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC INTRODUCTION Thank you for purchasing this purchase. To optimize the performance of your laser, please read these operating instructions carefully and familiarize yourself with the basic operations of this system. These instructions contain important safety information regarding the use and maintenance of this system as well.

  • Page 4: Unpacking Instructions

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC WHAT IS INCLUDED [CONTINUED] Name Pcs. Notes ELITE PRO FB4 60/100 laser w/ Integrated FB4 DMX IP65 housing Heavy duty flight case Estop safety box...

  • Page 5: Safety Notes

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC SAFETY NOTES WARNING! This projector is Class 4 laser product. It must never be used for audience-scanning applications. The output beam of the projector must always be at least 3 metres above the floor in the audience. See the Operating Instructions section for further information.

  • Page 6: Laser And Safety Notes

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC LASER AND SAFETY NOTES STOP AND READ ALL THE LASER SAFETY NOTES BELOW Laser Light is different from any other light sources with which you may be familiar. The light from this product can cause eye and skin injury if not set up and used properly.

  • Page 7: Laser Emission Data

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC LASER EMISSION DATA • Class 4 Laser Projector - Avoid Eye and Skin Exposure to Direct or Scattered Light! • This Laser Product is designated as Class 4 during all procedures of operation.

  • Page 8: Product Safety Label Location

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC PRODUCT SAFETY LABEL LOCATION ELITE 10 PRO FB4 (IP65) ELITE 20 PRO FB4 (IP65) ELITE 30 PRO FB4 (IP65) FRONT PANEL Hazard Warning Symbol 2.
  • Page 9 ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC PRODUCT SAFETY LABEL LOCATION [CONTINUED] ELITE 60 PRO FB4 (IP65) ELITE 100 PRO FB4 (IP65) FRONT PANEL Hazard Warning Symbol 2. Exposure Label 3. Laser Light Warning Label TOP PANEL 4.

  • Page 10: Product Safety Labels

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC PRODUCT SAFETY LABELS Logotype Danger Label Hazard Warning Symbol Aperture Label Aircraft Warning Label Interlocked Housing Label...
  • Page 11 ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC Laser Light Warning Label Certification Label This product is in conformity with performance standards for laser products under 21 CFR Part 1040.10 and 1041.11 except with respect to those...

  • Page 12: Interlock Connection Diagram

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC INTERLOCK CONNECTION DIAGRAM...

  • Page 13: Instructions For Using E-Stop System

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC INSTRUCTIONS FOR USING E-STOP SYSTEM Connect the E-stop box to the 3-pin interlock connector on the rear of the laser projector using a 3-PIN XLR cable.

  • Page 14: Theory Of Operation

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC THEORY OF OPERATION “UNITY Laser projector” is supplied with “E-Stop Box” and “Remote Interlock Bypass” including one cable. If user doesn’t need additional “User E-Stop Switch”, “Remote Interlock Bypass” should be inserted into “Remote Interlock Connector”...

  • Page 15: Operation

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC Caution – use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. This Laser Product is designated as Class 4 during all procedures of operation.

  • Page 16: Safety Tests

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC SAFETY TESTS E-STOP FUNCTION • With the projector operating and projecting laser light, press the red E-stop switch. The projector must shut off immediately.

  • Page 17: Model Specification

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC PRODUCT SPECIFICATION (ELITE 10 PRO FB4 (IP65)) Product Name: Unity ELITE 10 PRO FB4 (IP65) Type Of Laser: Full-color, Semiconductor diode laser system Guaranteed Optical Output: >11W...

  • Page 18: Front & Rear Panel View (Elite 10 Pro Fb4 (Ip65))

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC FRONT & REAR PANEL VIEW (ELITE 10 PRO FB4 (IP65)) Name Function Laser Aperture Laser output, do not look directly into this aperture. Aperture Masking Plate Can be moved up and down when two locklng bolts are loosened.

  • Page 19: Dimension Details (Elite 10 Pro Fb4 (Ip65))

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC DIMENSION DETAILS (ELITE 10 PRO FB4 (IP65))

  • Page 20: Product Specification (Elite 20 Pro Fb4 (Ip65))

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC PRODUCT SPECIFICATION (ELITE 20 PRO FB4 (IP65)) Product Name: Unity ELITE PRO FB4 (IP65) Type Of Laser: Full-color, Semiconductor diode laser system Guaranteed Optical Output: >22W...

  • Page 21: Front & Rear Panel View (Elite 20 Pro Fb4 (Ip65))

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC FRONT & REAR PANEL VIEW (ELITE 20 PRO FB4 (IP65)) Name Function Laser Aperture Laser output, do not look directly into this aperture. Aperture Masking Plate Can be moved up and down when two locklng bolts are loosened.

  • Page 22: Dimension Details (Elite 20 Pro Fb4 (Ip65))

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC DIMENSION DETAILS (ELITE 20 PRO FB4 (IP65))

  • Page 23: Product Specification (Elite 30 Pro Fb4 (Ip65))

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC PRODUCT SPECIFICATION (ELITE 30 PRO FB4 (IP65)) Product Name: Unity ELITE 30 PRO FB4 (IP65) Type Of Laser: Full-color, Semiconductor diode laser system Guaranteed Optical Output: >33W...

  • Page 24: Front & Rear Panel View (Elite 30 Pro Fb4 (Ip65))

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC FRONT & REAR PANEL VIEW (ELITE 30 PRO FB4 (IP65)) Name Function Laser Aperture Laser output, do not look directly into this aperture. Aperture Masking Plate Can be moved up and down when two locklng bolts are loosened.

  • Page 25: Dimension Details (Elite 30 Pro Fb4 (Ip65))

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC DIMENSION DETAILS (ELITE 30 PRO FB4 (IP65))

  • Page 26: Product Specification (Elite 60 Pro Fb4 (Ip65))

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC PRODUCT SPECIFICATION (ELITE 60 PRO FB4 (IP65)) Product Name: Unity ELITE 60 PRO FB4 (IP65) Type Of Laser: Full-color, Semiconductor diode laser system Guaranteed Optical Output: >103W...

  • Page 27: Front & Rear Panel View (Elite 60 Pro Fb4 (Ip65))

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC FRONT & REAR PANEL VIEW (ELITE 60 PRO FB4 (IP65)) Name Function Laser Aperture Laser output, do not look directly into this aperture. Aperture Masking Plate Can be moved up and down when two locklng bolts are loosened.

  • Page 28: Dimension Details (Elite 60 Pro Fb4 (Ip65))

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC DIMENSION DETAILS (ELITE 60 PRO FB4 (IP65))

  • Page 29: Product Specification (Elite 100 Pro Fb4 (Ip65))

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC PRODUCT SPECIFICATION (ELITE 100 PRO FB4 (IP65)) Product Name: Unity ELITE 100 PRO FB4 (IP65) Type Of Laser: Full-color, Semiconductor diode laser system Guaranteed Optical Output: >103W...

  • Page 30: Front & Rear Panel View (Elite 100 Pro Fb4 (Ip65))

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC FRONT & REAR PANEL VIEW (ELITE 100 PRO FB4 (IP65)) Name Function Laser Aperture Laser output, do not look directly into this aperture. Aperture Masking Plate Can be moved up and down when two locklng bolts are loosened.

  • Page 31: Dimension Details (Elite 100 Pro Fb4 (Ip65))

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC DIMENSION DETAILS (ELITE 100 PRO FB4 (IP65))

  • Page 32: Technical Information - Maintenance

    ELITE 10/20/30/60/100 PRO FB4 (IP65) Operational Manual (Revision 2024-11) UNITY Lasers s.r.o. | Unity Lasers, LLC TECHNICAL INFORMATION - MAINTENANCE GENERAL CLEANING INSTRUCTIONS - TO BE DONE BY USER Due to fog residue, smoke, and dust cleaning the external body of the projector should be carried out periodically to optimize light output.
