6.3
Reinitializing the control system
Make sure that the available power source meets the require-
ments described in Technical data.
1.
Press and hold the Close button.
– The FS 2500 closes as far as possible.
2.
Release the Close button.
3.
Press and hold the Close button.
– After approximately 10 seconds the FS 2500 slides in
small steps until completely closed.
– The motor produces a loud 'click' sound.
4.
Release the Close button.
– The control system has been initialized.
5.
Open / close the FS 2500 several times.
6.
Verify smooth operation.
Fig. 9 Reinitializing the control system
3398336D OI FS 2500
7
Annex
7.1
Technical data
Description
Operation
Power
Table 2: Technical data
7.2
EC-Declaration of Incorporation
WMS000193A
Fig. 10 EC-Declaration of Incorporation
7.3
UKCA-Declaration of Incorporation
Fig. 11 UKCA-Declaration of Incorporation
Annex | 7
Value
Continuous electric
12 V DC, 20 A
7 / 8
