- Page 1 Operating instructions Control element Electronic room thermostat Overview of control element Operating indicator Symbol - Off ON indicator Symbol - ON/OFF control Symbol - Permanent ON control Rotary knob (temperature/fan) Heating control switch...
- Page 2 About this document Purpose of the document These operating instructions are part of the product and provides the user with information on the safe operation of the unit. Using this document Before operating the heater, carefully read these operating instructions as well as the operating instructions for the heater.
- Page 3 Co ntrol Name of controls Warranty and liability Webasto shall not assume liability for defects or damage that are the result that the installation and operating instructions as well as the instructions contained therein being disregarded. This liability exclusion particularly applies for: ■...
- Page 4 Risk of poisoning and suffocation from exhaust fumes in closed rooms Do not switch on or operate the heater. Risk of injury from the defective unit Do not operate a defective heater. Contact a Webasto service workshop. Operation WARNING Risk of explosion in environments with combustible vapours, flammable dust and hazardous goods (e.g.
- Page 5 Switch on the heater Symbol Heating control Description Permanent ON For short breaks when only the cab temperature has drop- control ped but the instruments have not yet cooled down ON/OFF control For long breaks (e.g. over night) Set heating control switch to required heating level. ON LED indicator lights up.
-
Page 6: Troubleshooting
Do you have any technical queries or a problem with your unit? Country-specific telephone numbers for our branches can be found on the Webasto service point flyer or under www.webasto.com. Technical data Operating voltage range: 12 V to 24 V Permissible ambient temperature: ■... - Page 7 In multilingual versions the German language is binding. The telephone number of each country can be found in the Webasto service center leaflet or the website of the respective Webasto represen- tative of your country. Webasto Thermo & Comfort SE...
