  • Page 1 Operating Instructions FS 2500 Galeon Marine Shading Systems English...

  • Page 2: Table Of Contents

    Tensioning outer fabric .......... 5 Trouble shooting ........  5 Manual operation .......  6 Manually moving the folding shade ...... 6 Re-initialization of the control system ...... 6 Annex .......... 7 Technical data ............ 7 EC-Declaration of Incorporation.........  7 3310122B OI FS 2500 Galeon...

  • Page 3: About This Document

    The FS 2500 Galeon is an electrically operated marine folding product and provide the information required to ensure correct shade system for comfort purposes. The FS 2500 Galeon is de- and safe operation. signed for use on motor and sailing yachts.

  • Page 4: Operation

    One touch closing NOTE When this option is installed the folding shade closes up to The illustrations show the standard Webasto control 200 mm from the fullly closed position after momentarily push- switch. The installed control switch can be different. ing the close button. This position is for safety reasons to make sure nobody gets trapped between the folding shade and the deck structure.

  • Page 5: Maintenance

    Fig. 4 Cleaning and greasing Initialization not Low power at mo- Check battery. Apply a thin layer of grease (Isoflex® Topas L32) to the in- possible. Increase wire thick- side of the guides. ness. 3310122B OI FS 2500 Galeon 5 / 8...

  • Page 6: Manual Operation

    In case the folding shade is closed and locked, first unlock it Press and hold the close button. by opening the folding shade for at least 10 cm. – After approx. 10 s the FS 2500 Galeon slides with small Gain access to the motor assembly. steps until it is completely closed.

  • Page 7: Annex

    Annex | 7 Annex Technical data Description Value Operation Continuous electric Power 12 VDC, 20 A EC-Declaration of Incorporation Fig. 9 EC-Declaration of Incorporation 3310122B OI FS 2500 Galeon 7 / 8...
  • Page 8 These are the original instructions. The English language is binding. You can request your language if it is missing. The telephone number of each country can be found in the Webasto ser- vice centre leaflet or the website of the respective Webasto representative of your country.
