BRUCIATORI A GAS BISTADIO TWO-STAGE GAS BURNERS ITALIANO TBG 45 P Manuale istruzioni per l'installazione, l'uso e la manutenzione 17210010 Instruction manual for TBG 60 P installation, use and maintenance 17280010 ISTRUZIONI ORIGINALI (IT) ORIGINAL INSTRUCTIONS (IT) 0006160178_202211...
ITALIANO ITALIANO SOMMARIO Avvertenze per l'uso in condizioni di sicurezza ..............................2 Caratteristiche tecniche ......................................6 Materiale a corredo ......................................7 Campo di lavoro .......................................7 Targa identificazione bruciatore..................................7 Dati registrazione prima accensione ................................8 Descrizione componenti ....................................9 Quadro elettrico ........................................9 Dimensioni di ingombro ....................................10 Linea di alimentazione....................................
ITALIANO AVVERTENZE PER L'USO IN CONDIZIONI DI • Se il bruciatore deve essere utilizzato all'interno di un impianto/ processo, si prega di contattare gli uffici commerciali Baltur. SICUREZZA • La data di produzione dell'apparecchio (mese, anno) sono indicati sulla targa identificazione bruciatore presente sull'apparecchio.
Page 5
• L’eventuale riparazione dei prodotti dovrà essere effettuata • Prima di avviare il bruciatore e almeno una volta all’anno, far solamente da un centro di assistenza autorizzato da BALTUR o dal effettuare da personale professionalmente qualificato le seguenti suo distributore locale, utilizzando esclusivamente ricambi originali.
Page 6
ITALIANO AVVERTENZE PARTICOLARI PER L’USO DEL GAS. (pioggia, sole, ecc.) a meno che non sia espressamente previsto; • Verificare che la linea di adduzione e la rampa siano conformi alle - non permettere che l’apparecchio sia usato da bambini o da norme e prescrizioni vigenti.
Page 7
ITALIANO A CURA DELL'INSTALLATORE (fare riferimento a EN 60947-5-1: 2016, Allegato K). • Installare un idoneo sezionatore per ciascuna linea di alimentazione - Si raccomanda che il dispositivo di arresto di emergenza sia di del bruciatore. colore rosso e la superficie dietro di esso sia di colore giallo. •...
ITALIANO CARATTERISTICHE TECNICHE MODELLO TBG 45 P TBG 60 P Potenza termica massima metano Potenza termica minima metano mg/kWh ¹) emissioni metano Classe 3 Classe 3 Funzionamento Bistadio Bistadio Trasformatore metano 50 hz 26 kV - 40 mA - 230/240 V 26 kV - 40 mA - 230/240 V Stm³/h...
ITALIANO MATERIALE A CORREDO MODELLO TBG 45 P TBG 60 P Guarnizione flangia attacco bruciatore Cordone isolante Prigionieri N° 4 M 12 N° 4 M 12 Dadi esagonali N° 4 M 12 N° 4 M 12 Rondelle piane N° 4 Ø 12 N°...
ITALIANO DATI REGISTRAZIONE PRIMA ACCENSIONE Modello: Data: ora: Tipo di gas Indice di Wobbe inferiore Potere calorifico inferiore Stm³/h Portata min gas Stm³/h Portata max gas Potenza min gas potenza max gas hPa (mbar) Pressione gas di rete hPa (mbar) Pressione gas a valle dello stabilizzatore CO (alla potenza minima) CO2 (alla potenza minima)
ITALIANO APPLICAZIONE DEL BRUCIATORE ALLA LINEA DI ALIMENTAZIONE Lo schema di principio della linea di alimentazione gas è riportato CALDAIA nella figura sotto. Installare, a monte della valvola gas, una valvola di intercettazione MONTAGGIO GRUPPO TESTA manuale e un giunto antivibrante, disposti secondo quanto indicato •...
ITALIANO MONTAGGIO RAMPA GAS Sono possibili diverse soluzioni di montaggio (1), (2), (3) , della rampa gas. Il bruciatore viene fornito con attacco per rampa gas rivolto verso il basso. Se si desidera invertire il lato di ingresso rampa per consentire il montaggio della rampa gas secondo la configurazione (1), seguire la procedura descritta al paragrafo: "Predisposizione pre attacco rampa verso l'alto".
ITALIANO COLLEGAMENTI ELETTRICI • Le linee elettriche devono essere distanziate dalle parti calde. • L’installazione del bruciatore è consentita solo in ambienti con grado di inquinamento 2 come indicato nell’allegato M della norma EN 60335-1:2008-07. • Assicurarsi che la linea elettrica a cui si vuol collegare l’apparecchio sia alimentata con valori di tensione e frequenza adatti al bruciatore.
Page 16
ITALIANO CAUTELA / AVVERTENZE gli alloggiamenti dei cavi per le spine sono previsti rispettivamente per cavo Ø 9,5÷10 mm e Ø 8,5÷9 mm, questo per assicurare il grado di protezione IP 44 (Norma CEI EN60529) relativamente al quadro elettrico. Avvitare le viti (1) esercitando una coppia di serraggio adeguata ad assicurare la corretta tenuta, per richiudere il coperchio del quadro elettrico.
ITALIANO DESCRIZIONE DEL FUNZIONAMENTO TBG 45P - 60P Alla chiusura dell’interruttore generale e dell’interruttore I/O Interruttore MARCIA / ARRESTO del quadro elettrico, se i termostati sono chiusi, la tensione raggiunge l’apparecchiatura di comando e controllo che avvia il bruciatore (accensione led 7). Viene così...
ITALIANO ACCENSIONE E REGOLAZIONE GAS strumento che la percentuale di ossido di carbonio (CO) presente nei fumi non superi il valore imposto dalla normativa vigente al METANO momento dell’installazione. • Verificare ripetutamente che l’erogazione della prima fiamma • Verificare che ci sia acqua in caldaia e che le saracinesche avvenga correttamente.
Page 19
ITALIANO • Aprire della quantità che si presume necessaria, il regolatore • Verificare l’efficienza dei termostati o pressostati di caldaia manuale di portata del gas per la seconda fiamma (fiamma (l’intervento deve arrestare il bruciatore). principale). CAUTELA / AVVERTENZE • Inserire, ora, nuovamente il bruciatore chiudendo l’interruttore Controllare che l’accensione avvenga regolarmente.
ITALIANO MISURAZIONE DELLA CORRENTE DI IONIZZAZIONE Per misurare la corrente di ionizzazione, togliere il ponticello dai morsetti 30-31 del circuito stampato a bruciatore spento.Collegare agli stessi morsetti i terminali di un microamperometro di scala adeguata e far ripartire il bruciatore. Una volta comparsa la fiamma, sarà...
ITALIANO APPARECCHIATURA DI COMANDO E CONTROLLO LME... FUNZIONAMENTO. Il pulsante di sblocco «EK...» è l’elemento principale per poter accedere a ROSSO tutte le funzioni di diagnostica (attivazione e disattivazione), oltre a sbloccare GIALLO il dispositivo di comando e controllo. VERDE Sia «LED»...
Page 22
ITALIANO DIAGNOSI DELLE CAUSE DI MALFUNZIONAMENTO E BLOCCO. In caso di blocco bruciatore nel pulsante di sblocco sarà fissa la luce rossa. Premendo per più di 3 sec. la fase di diagnosi verrà attivata (luce rossa con lampeggio rapido), nella tabella sottostante viene riportato il significato della causa di blocco o malfunzionamento in funzione del numero di lampeggi (sempre colore rosso).
Page 23
ITALIANO SCHEMA DEI COLLEGAMENTI E CONTROLLO DELLA SEQUENZA DI AGK25... Resistenza PTC LAVORO DELL'APPARECCHIATURA LME 22... Messaggio di errore (allarme) Interfaccia di Comunicazione del Bruciatore BV... Valvola del Combustibile Indicatore di Posizione Chiusa Dbr.. Ponticello cablaggio EK.. Pulsante di reset del blocco remoto (interno) EK2 Pulsante di reset del blocco remoto Sonda di Ionizzazione Segnale di Fiamma...
ITALIANO MANUTENZIONE Effettuare almeno una volta all’anno e comunque in conformità alle norme vigenti, l’analisi dei gas di scarico della combustione verificando la correttezza dei valori di emissioni. • Verificare che tutti i componenti della testa di combustione siano in buono stato, non deformati e privi di impurità o depositi derivanti dall'ambiente di installazione e/o dalla combustione.
ITALIANO BRUCIATORE DI GAS A DUE STADI Quando un bruciatore bistadio è installato su una caldaia per la produzione di acqua calda ad uso riscaldamento, deve essere collegato in modo da lavorare alla potenza massima; arrestandosi completamente, senza passare al primo stadio, quando la temperatura prestabilita viene raggiunta.
ITALIANO TEMPI DI MANUTENZIONE Descrizione particolare Azione da eseguire TESTA DI COMBUSTIONE CONTROLLO VISIVO, INTEGRITA' CERAMICHE, SMERIGLIATURA ESTREMITA', VERIFICARE DISTANZA, ELETTRODI ANNO VERIFICARE CONNESSIONE ELETTRICA DISCO FIAMMA CONTROLLO VISIVO INTEGRITA' EVENTUALI DEFORMAZIONI, PULIZIA ANNO CONTROLLO VISIVO, INTEGRITA' CERAMICHE, SMERIGLIATURA ESTREMITA', VERIFICARE DISTANZA, SONDA DI IONIZZAZIONE ANNO VERIFICARE CONNESSIONE ELETTRICA...
ITALIANO VITA ATTESA La vita attesa dei bruciatori e dei relativi componenti dipende molto dal tipo di applicazione su cui il bruciatore è installato, dai cicli, dalla potenza erogata, dalle condizioni dell’ambiente in cui si trova, dalla frequenza e modalità di manutenzione, ecc. ecc. Le normative relative ai componenti di sicurezza prevedono una vita attesa di progetto espressa in cicli e/o anni di funzionamento.
ITALIANO PRECISAZIONI SULL'USO DEL PROPANO PERICOLO / ATTENZIONE La potenza massima e minima (kW) del bruciatore, è considerata • Valutazione, indicativa, del costo di esercizio; con combustibile metano che coincide approssimativamente - 1 m3 di gas liquido in fase gassosa ha un potere calorifico con quella del propano.
ITALIANO ISTRUZIONI PER L'ACCERTAMENTO DELLE CAUSE DI IRREGOLARITÀ NEL FUNZIONAMENTO E LA LORO ELIMINAZIONE IRREGOLARITÁ POSSIBILE CAUSA RIMEDIO Invertire l'alimentazione (lato 230V) del trasformatore di accensione e verificare con Disturbo della corrente di ionizzazione da micro-amperometro analogico. parte del trasformatore di accensione. Sostituire il sensore fiamma.
Page 37
ENGLISH ENGLISH SUMMARY Warnings for use in safety conditions ..................................2 Technical specifications ......................................6 Standard accessories .......................................7 Operating range .......................................7 Burner identification plate ....................................7 Data recorded during first start-up ..................................8 Component description ....................................9 Electrical panel .........................................9 Overall dimensions ......................................10 Supply line ........................................11 Burner connection to the boiler .....................................
• If the burner is to be used inside a system/process, please contact the sales offices Baltur. • The equipment production date (month, year) is written on the burner identification plate located on the equipment.
Page 39
Contact only qualified personnel. - At the end of the adjustment procedures, check that all the • Any product repairs must only be carried out by BALTUR authorised locking devices of mechanical securing systems are properly assistance centres or by its local distributor using only original spare tightened.
Page 40
ENGLISH SPECIAL PRECAUTIONS WHEN USING GAS. - The power supply cable for the equipment must not be replaced • Check that the feed line and the train comply with current law and by the user. If the cable is damaged, turn the equipment off and regulations.
Page 41
ENGLISH TO BE CARRIED OUT BY THE INSTALLER - The emergency activation device must be clearly visible and • Install a suitable disconnecting switch for each burner supply line. easily reachable and actionable in the immediate vicinity of the • The disconnection must be carried out by means of a device burner.
ENGLISH TECHNICAL SPECIFICATIONS MODEL TBG 45 P TBG 60 P Maximum natural gas heat power Minimum natural gas heat power mg/kWh ¹) natural gas emissions Class 3 Class 3 Operation Two-stage Two-stage 50 Hz natural gas transformer 26 kV - 40 mA - 230/240 V 26 kV - 40 mA - 230/240 V Stm³/h...
ENGLISH STANDARD ACCESSORIES MODEL TBG 45 P TBG 60 P Burner coupling flange gasket Insulating cord Stud bolts No. 4 M 12 No. 4 M 12 Hexagon nuts No. 4 M 12 No. 4 M 12 Flat washers No. 4 Ø 12 No.
Page 44
ENGLISH DATA RECORDED DURING FIRST START-UP Model: Date: Time: Type of gas Lower Wobbe index Lower calorific power Stm³/h Min. gas flow rate Stm³/h Max. gas flow rate Min. gas power Max. gas power hPa (mbar) System gas pressure hPa (mbar) Gas pressure downstream from stabilizer CO (at minimum power) CO2 (at minimum power)
ENGLISH COMPONENT DESCRIPTION Combustion head Seal Burner connection flange Combustion head adjustment device Scroll cover Gas train connector flange Electrical panel Motor Air regulation servomotor Manual air regulation system Air pressure switch Burner identification plate ELECTRICAL PANEL Control box Ignition transformer Motor contactor 7-pole connector 4-pole connector...
ENGLISH OVERALL DIMENSIONS Model E Ø F Ø TBG 45 P 140 ÷ 300 TBG 60 P 140 ÷ 300 Model LØ N Ø TBG 45 P 200 ÷ 245 TBG 60 P 225 ÷ 300 10 / 34 0006160178_202211...
ENGLISH BURNER CONNECTION TO THE BOILER SUPPLY LINE The figure below shows the gas supply line block diagram. Install a manual shut-off valve and an anti-vibration joint upstream of HEAD UNIT ASSEMBLY the gas valve, as shown in the diagram. •...
ENGLISH ASSEMBLING THE GAS TRAIN The gas train can be assembled in different ways: (1), (2), (3). The burner is supplied with the gas train connection facing downward. If you wish to invert the direction of train entrance to allow the gas train to be assembled in configuration (1) follow the procedure described in the section entitled: “Preparation for connection with train turned upward”.
ENGLISH ELECTRICAL CONNECTIONS • The power lines must be distanced from the hot parts. • The burner installation is allowed only in environments with pollution degree 2 as indicated in annex M of the EN 60335- 1:2008-07 regulation. • Make sure that the power line to which the unit will be connected, has frequency and voltage values suitable for the burner.
Page 50
ENGLISH CAUTION / WARNINGS cable housings for the plugs are provided respectively for cable Ø 9.5÷10 mm and Ø 8.5÷9 mm to ensure IP 44 protection rating (Standard IEC EN60529) for the electrical panel. To close the electrical panel lid, tighten the screws (1) with adequate torque to ensure the correct seal.
ENGLISH DESCRIPTION OF TBG 45P - 60P OPERATION When the main switch and the I/O switch START/STOP switch on the electrical panel are on, if the thermostats are on, voltage will reach the command and control device, which starts up the burner (led 7 switches on).
ENGLISH NATURAL GAS IGNITION AND REGULATION of the second flame, reconnect the previously disconnected 4-pole connector for burners TBG 45P-60P. • Check that there is water in the boiler and that the gate valves of • Repeatedly check that the first flame is properly supplied. After the system are open.
Page 53
ENGLISH • Open the manual regulator for supplying gas for the second flame to limit the quantity of air to the lowest amount possible needed (main flame) of the quantity deemed necessary. for safe ignition, even in the most difficult circumstances. •...
ENGLISH IONISATION CURRENT MEASUREMENT To measure the ionisation current, remove the jumper between terminals 30-31 on the printed circuit with the burner off.Connect to the terminals a microammeter having a suitable scale to have the burner restart. Once the flame has appeared it will be possible to measure the ionisation current, the minimum value of which to ensure the working of the equipment is shown in the specific wiring diagram.
ENGLISH CONTROL AND COMMAND EQUIPMENT LME... OPERATION. The reset button «EK...» is the main element to access all diagnostics functions (activation and deactivation) and serves to unlock the command YELLOW and control device. GREEN Both «LED» and «EK...» are positioned under the transparent button. Pressing this button, you reset the command and control equipment. There are two diagnostics choices: 1.
Page 56
ENGLISH MALFUNCTION AND LOCK CAUSE DIAGNOSTICS. In the event of a burner lock-out, the red light on the reset button will be fixed. To activate the diagnosis phase (red light blinking fast) press the button for more than 3 seconds. The table below indicates the meaning of the block or fault cause according to the number of flashings (always red).
Page 57
ENGLISH WIRING DIAGRAM AND OPERATION CONTROL SEQUENCE OF AGK25... PTC resistance EQUIPMENT LME 22... Error message (alarm) Burner Communication Interface BV... Fuel Valve Closed Position Indicator Dbr.. Wiring jumper EK.. Remote lockout reset button (internal) EK2 Remote lockout reset button ION__tab_Ionisation probe Flame Signal FSV Flame signal amplifier...
ENGLISH DIAGRAM FOR REGULATING THE ELECTRODE DISK DISTANCE TBG 45P-ME TBG 60P-ME 1 - Ionisation electrode 2 - Ignition electrode TBG 45P TBG 60P 3 - Flame disc 4 - Mixer 5 - Gas delivery pipe E - WARNING: nozzle hole outlet near the electrode tip. AIR REGULATION ON THE COMBUSTION HEAD It may be necessary to have high air pressure upstream of the disc, so as to prevent flame pulses.
Page 59
ENGLISH BURNER Value indicated by index 4 SQN72 SERVOMOTOR CAM ADJUSTMENT. XA4A20 FOR TBG 45P 3 ÷ 31 0 ÷ 3,2 TBG...P TBG 60P 6 ÷ 34 0 ÷ 3.2 • Loosen the screw (1) • Turn screw (2) to position the combustion head (3), referring to index (4) •...
ENGLISH MAINTENANCE Analyse combustion gases and check that the emission values are correct at least once a year, in compliance with current law. • Check that all components of the combustion head are in good condition, have not been deformed and are free from impurities or deposits deriving from the installation environment and/or from combustion.
ENGLISH TWO STAGE GAS BURNER When the two-stage burner is installed on a boiler for the production of hot water for heating purposes, it must be connected so it can operate at the maximum output by stopping completely, without switching to the first-stage operation, when the set temperature is reached.
ENGLISH MAINTENANCE TIME Part description Action to be performed COMBUSTION HEAD VISUAL INSPECTION OF THE INTEGRITY OF CERAMICS. TIP GRINDING, CHECK DISTANCE, CHECK ELECTRODES YEAR ELECTRICAL CONNECTION FLAME DISC INTEGRITY VISUAL CHECK FOR ANY DEFORMATIONS, CLEANING, YEAR VISUAL INSPECTION OF THE INTEGRITY OF CERAMICS. TIP GRINDING, CHECK DISTANCE, CHECK IONISATION PROBE YEAR ELECTRICAL CONNECTION...
ENGLISH EXPECTED LIFESPAN The expected lifespan of burners and relevant components depends very much from the type of application on which the burner is installed, from cycles ,of delivered power, from the conditions of the environment in which it is located, from maintenance frequency and mode, etc. Standards about safety components provide for a project expected lifespan expressed in cycles and/or years of operation.
ENGLISH SPECIFICATIONS FOR PROPANE USE DANGER / ATTENTION The maximum and minimum power (kW) of the burner refers • Operating costs approximate assessment; to natural gas which is more or less the same as with propane. - 1 m3 of liquid gas in gaseous stage has a lower heating •...
ENGLISH INSTRUCTIONS FOR DETERMINING THE CAUSE LEADING TO IRREGULARITIES IN THE OPERATION AND THEIR ELIMINATION IRREGULARITY POSSIBLE CAUSE REMEDY Invert the ignition transformer power supply (230V side) and check using an analogue Disturbance to ionization current from the micro-ammeter. ignition transformer. Replace the flame sensor.
Page 69
ENGLISH CONTROL BOX GNYE GREEN / YELLOW VALVE SEAL CONTROL BLUE Flame sensor BROWN EXTERNAL LOCK INDICATOR LIGHT/ AUXILIARY HEATING BLACK ELEMENT OPERATION LAMP BLACK CONNECTOR WITH OVERPRINT OPERATION INDICATOR LIGHT LOCK-OUT WARNING LIGHT “2ND STAGE OPERATION LIGHT“ FAN MOTOR CONTACTOR FAN MOTOR HOUR METER AIR PRESSURE SWITCH...
Page 72
