  • Page 1 GARO TWIN Assembly instructions / End User Instruction (EN) GARO AB Box 203, SE–335 25 Gnosjö Phone: +46 (0) 370 33 28 00 info@garo.se garo.se...

  • Page 2: Table Of Contents

    Connect TWIN to local wifi network Ethernet settings RFID (option) Outlet options * G-Cloud Charge current settings / DLM Software Updates / Identification Firmware update for TWIN not connected to internet via Wifi or LAN Workingflow RFID with multiple wallboxes Care Technical data...

  • Page 3: About This Manual

    This document contains general descriptions which are verified to be accurate at the time of printing. However, because continuous improvement is a goal at GARO, we reserve the right to make product and software modifications at any time. This range is subject to continual product development.

  • Page 4: Cautions

    TWIN itself. Note that 1-phase charging is common in electric vehicles and L1 and L2 in the TWIN is used for this purpose. Poor quality electricity may harm the TWIN and or the vehicle. An example of such source of poor quality Ventilation signal from EV is not supported.

  • Page 5: Installation Of Standalone Twin

    Note: Wall installation of TWIN requires a minimum 20mm distance between the wall and the TWIN to ensure correct cooling, see (figure 4). When TWIN is installed on a pole, the holes at the back side of the TWIN should be covered/closed by attached screws, see (figure 7).
  • Page 6 INSTALLATION OF STANDALONE TWIN 4. Check/set the dip 1-3 on SW1 CC2 to the max Ampere (A) that the outlets can load/charge, for example TWIN11kW: 16+16A=32A Dip switch SW1 is located in the center of left hand side of CC2, O 6mm see (figure 9).
  • Page 7 (A) separate for left/right hand ON OFF ON OFF side of the TWIN. Available range is 6A – MAX32A, see (figure 3=OFF 3=OFF 8). This is normally not necessary to do at a standard installation.
  • Page 8 Cu = 2,5Nm, Al = 4Nm (figure 11) 11. Test the TWIN with a test instrument or test to charge an electric vehicle to ensure that the TWIN is working properly. 12. Doublecheck that the Warranty Form is filled in completely, sign with name, date and company that the warranty is valid.
  • Page 9 INSTALLATION OF STANDALONE TWIN Dip Switch Information SW1 CC2 ON OFF Datalink Endtermination ON, OFF ON = Master Mode, OFF = Slave mode Remote enable input function. ON (default) = Open circuit, OFF = Closed circuit Fuse value in mains cabinet, see below table for settings...

  • Page 10: Remote Enable Signal

    INSTALLATION OF STANDALONE TWIN Remote enable signal Via a potential-free contact (relay, timer etc) the TWIN can be remotely enabled/disabled. The cable is connected to terminals on CC2, see picture 11 (remote control). Enable of the TWIN can be done in two ways: 1.
  • Page 11 INSTALLATION OF STANDALONE TWIN Termination 6-8 Termination 5-8 Termination 7-9 Termination 10-12 (figure 15)

  • Page 12: Dynamic Load Management (Dlm) For Stand Alone Twin

    The energy meter continually measures the total energy consumption for each phase. The data is transmitted to the TWIN, To activate DLM, a Modbus energy meter must be installed in that then is reducing the charging current when necessary in order the supply distribution box.

  • Page 13: Dynamic Load Management (Dlm) For Twin In A Grid

    It is also possible to install a 2nd Modbus energy meter when you need to measure the consumed energy at more than one place. TWIN master require an installed wifi-module. The following energy meters are approved: •...
  • Page 14 See picture 13, 14. • Garo GNM3D-LP-RS485 • Garo GMI3D-LP It is allowed to mix TWIN with GLB Wallbox in this type of grid, • Garo GNM3T-LP-RS485 (current transformer 3-phase. Max and the limit is max 50pcs “outlets”, current is based on current transformer) (TWIN = 2pcs outlets and GLB = 1pcs outlet).
  • Page 15 TWIN CLUSTER INSTALLATION Schematic image with TWIN placed in the center of the cluster TWIN SW1 CC2 SW1 CC2 SW1 CC2 SW1 CC2 SLAVE SLAVE MASTER SLAVE End term End term (figure 20) Settings explanation of Dip 5, 6 on SW1 CC2...

  • Page 16: Rfid Reader Installation

    2. Assembly the RFID readers according (figure 23) - (figure 26). (figure 22) Note: Both DIP switches should set to ON on both RFID readers, see picture 18. A wifi module needs to be installed to the Master TWIN. Note: RFID can read Mifare Classic tags. (figure 25) (figure 23)

  • Page 17: Rfid Settings For Stand Alone Twin

    A maximum of 25pcs TWIN can be installed in cluster via Data- link (twisted pair cable). It is also possible to mix TWIN and GLB in data-link cluster. In that case, the maximum is 50pcs charging points (TWIN = 2pcs, GLB = 1pcs) See (figure 29)(figure 30).
  • Page 18 INSTALLATION OF STANDALONE TWIN Schematic image with TWIN Master placed to the left of the cluster TWIN SW1 CC2 SW1 CC2 SW1 CC2 SW1 CC2 MASTER SLAVE SLAVE SLAVE End term End term (figure 29) Schematic image with TWIN Master placed in the center of the cluster...

  • Page 19: Lan Connection Via Rj45

    NOTE! Make sure that the network you connect your Wallbox to has a firewall towards Internet to prevent unauthorized access to It is possible to connect the TWIN to a LAN via the RJ45 port the Wallbox. on the wifi module. Default settings is DHCP. More options are available in the web interface.

  • Page 20: M-Bus Information

    Dimensional sketch M-Bus information Connection of M-Bus (only for TWIN with M-Bus energymeters) Terminal 300 = M+ Terminal 301 = M- (figure 32)

  • Page 21: Electrical Diagram

    INSTALLATION OF STANDALONE TWIN Electrical diagram Q1 = Main Breaker 100A P1 = Energymeter Left Outlet P2 = Energymeter Right Outlet -KF1 -KF1 FB1 = RCCB Left Outlet FB2 = RCCB Right Outlet -RFID1 -RFID1 -RFID2 -RFID2 -CC1 -CC1 -CC2...
  • Page 22 (figure 34)
  • Page 23 (figure 35)
  • Page 24 (figure 36)
  • Page 25 (figure 37)

  • Page 26: User Manual

    TWIN, the left hand side is prioritized. The electrical current can also be reduced by the Dynamic Load Management (DLM) functions. If the TWIN is equipped with outlets, it is important to use correct charging cable. For example, if you want to use 32A from the TWIN, you must use a 32A charging cable.

  • Page 27: Web Interface

    The wifi module is set to ”Accesspoint” as default and in this mode Note: When the TWIN is connected to your local network, you you should search after the wallbox SSID in your device. should use the address chargebox.garo.se in the web browser.

  • Page 28: List Of All Different Statues

    WEB INTERFACE List of all different statues...

  • Page 29: Home Meny

    WEB INTERFACE Home meny Click to set time Double click GARO logo for extended information. Wallbox status Dropdown list *: Available for charging Not available for charging Schedule An installed DLM meter is visible here. Note, it can take up to 5min before the DLM meter is visible after power * N/A for older wallboxes Car and text shows present status.
  • Page 30 Chargecontroller card changed. Click here if you want to copy all old chargning history to the chargecontroller card. Available for charging means that the TWIN is activated. Not available for chargning mean that the TWIN is deactivated. * Schedule means that you can set periods when the TWINes should be activated.
  • Page 31 WEB INTERFACE Click the + to show extended information. The information is updated every minute (only displayed with installed DLM meter) Click Refresh to search for connected wallboxes Multiple connected wallboxes are shown in a list Click Identify to start white blink and ticking sound from chosen wallbox.

  • Page 32: Energy Meny

    WEB INTERFACE Energy meny In wallboxes without internal energymeter, Energy meter not installed is shown. Choose energy meter TWIN with internal energymeter show energy consumption here. Choose consumption period Choose wanted energymeter (cluster installation) Settings Click + to see extended information.

  • Page 33: Wifi Settings

    Connected to router in the dropdown list. Click Scan for wifi-networks. Click wanted network, type in password and click Save. Save Make sure your unit is connected to same network as your wallbox. Type in chargebox.garo.se in a webbrowser and follow the instructions.

  • Page 34: Ethernet Settings

    Web interface Ethernet settings You can connect the wallbox to a LAN via wifi modules ethernet port. Make sure that your local network uses a secure firewall to avoid unwanted access to the wallbox from internet. Ethernet-settings – More information shows the Ethernetports MAC adress.

  • Page 35: Rfid (Option)

    Add a referens to each tag.. Choose selected a specific wallbox or all wallboxes. For Twin, you can choose left or right hand side. Click Save for each registered tag.

  • Page 36: Outlet Options

    The service means that the wallbox will be connected to a cloud server. The energy consumsion is stored in G-Cloud. Via G-Cloud website, you can create energy reports for each energymeter. G-Cloud subscription is ordered at www.garo.se Tick the box to activate the function.

  • Page 37: Charge Current Settings / Dlm

    Slide the slider to wanted minimum charging current and click Save. * The function is not available for older TWIN. Limit charge current is possible by ticking the box. Click Add new period and set wanted values.
  • Page 38 Web interface LB Meter settings are shown in cases with DLM meter adress 100 or 101 installations Currentlimited (A): Set Distribution board fuse size. In systems where Power-limit is neccessary, tick the box and set the Powerlimit value wanted in the distribution board.
  • Page 39 Web interface Set wanted value for each wallbox in the system. Click Save after changed settings. Note, in systems with multiple connected wallboxes, make the setting for each box in the system. All wallboxes are shown in a list.

  • Page 40: Software Updates / Identification

    By Computer / Android mobile or tablet: 1. Open https://www.webel-online.se/wifi and download the file. (device must be connected to internet) 2. Connect your device to the TWIN Wifi network. (Search for TWIN<the box serial no> ) 3. Open http://172.24.1.1:8080/update in your web- browser 4.

  • Page 41: Workingflow Rfid With Multiple Wallboxes

    Click Save. • Repeat step 4 until all tags are registred. Care We recommend that you clean the TWIN Wallbox with a soft, dry cloth. Never use detergent. Exercize the RCCBs every 6th month. See section “Resetting/ Conditioning of RCCB”...
  • Page 42 Indication Error type Action Solid red light RCCB has tripped or EV earth Reset. Refer to section on resetting check error is detected. the residual-current or personal protective current breaker. Solid red light for 3 sec RFID tag not accepted. Red fast flash DC current >6mA - charging has stopped.

  • Page 43: Technical Data

    Technical data Product type All TWIN models Standards / Directives IEC 61851-1 and IEC 61439-7 EMC Classification: 2014/30/EU Installation method: Ground / Wall Installation environment: Indoor / Outdoor Location type: Non-restricted Access Rated Voltage: 230V / 400V 50Hz Installation systems:...
