RS-232: Null Modem Connection (No Hardware Handshaking)
This type of connection can be used to connect the radio to a computer or field
device communication port.
Note: If the serial device is configured with to use the CTS line, then a jumper is
required between the RTS and the CTS line on the radio connection.
RS-422
