Start Here
User Manual
Radio Specifications
Frequency
Protocols
Security
Network Topology
Error Detection
Radio Type
Transmit Power
(Programmable)
Channel data rates
Receiver Sensitivity
(Typical)
Outdoor Range
Hardware Specifications
Enclosure
Size
Ethernet Port
Serial Data Port
Antenna Ports
Weight
Operating Temp
Humidity
Vibration
Shock
External Power
Power Consumption
Page 14 of 109
RadioLinx® Industrial Frequency Hopping Ethernet Radios
902 MHz to 928 MHz
All standard IEEE 802.3 protocols
128 bit AES encryption
Point-to-point, point-to-multipoint, store and forward
repeater
32 bit CRC, ARQ (Automatic Resend Query)
Frequency Hopping Spread Spectrum
100 mW to 1 W (Programmable)
20 dBm to 30 dBm (Programmable)
1.1 Mbps or 345 kbps (Programmable)
1.1 Mbps: -98 dBm @ 10-6 BER
345 kbps: -106 dBm @ 10-6 BER
30+ miles pt-pt with high gain directional antennas and RF
line-of-sight
Extruded aluminum with DIN and panel mount
117 x 112 x 41 mm / 4.6 x 4.4 x 1.6 inches (W x H x D)
10/100 Base-T connector, shielded RJ45
IEEE 802.3, 802.3u, 802.3x
RS-232, DB9 / RS-422 and RS-485
300 bps to 230 kbps
(1) RP-SMA connector
1.0 lbs (454g)
-40°F to 149°F (–40°C to +65°C)
Up to 100% RH, without condensation
IEC 60068-2-6 (20g, 3-Axis)
IEC 60068-2-27 (5g, 10 Hz to 150 Hz)
9 Vdc to 24 Vdc
12 W peak
