1.1.2 Product Specifications - RLX-IFH24E

The RLX-IFH24E provides powerful and secure wireless Ethernet
communications and is well suited for demanding, long-range (up to 15+ miles)
SCADA and other Ethernet applications in tough environments. Operating in the
internationally license-free 2.4 GHz band, the RLX-IFH24E offers an alternative
when 900 MHz radios cannot be used due to government regulations, band
saturation, or customer preference. The RLX-IFH24E is user configurable as a
master, repeater and remote radio and employs the 128 bit AES encryption
algorithm approved by the United States government for top secret information.
RLX-IFH24E radios are quickly and easily configured using the included,
graphical ControlScape software. An OPC server software is also included and
allows users to monitor radio network health with any OPC client based HMI
software.
Radio Specifications
Frequency
Protocols
Security
Network Topology
Error Detection
Radio Type
Transmit Power
Channel data rates
Receiver Sensitivity
(Typical)
Outdoor Range
Hardware Specifications
Enclosure
Size
Ethernet Port
Serial Data Port
Antenna Ports
Weight
Operating Temp
Humidity
Vibration
Shock
External Power
Power Consumption
ProSoft Technology, Inc.
November 19, 2013
2.400 GHz to 2.4835 GHz
All standard IEEE 802.3 protocols
128 bit AES encryption
Point-to-point, point-to-multipoint, store and forward
repeater
32 bit CRC, ARQ (Automatic Resend Query)
Frequency Hopping Spread Spectrum
100 mW to 1W (FCC - A model – Programmable)
10 mW to 100 mW (ETSI - E model – Programmable)
1.1 Mbps or 345 kbps (Programmable)
1.1 Mbps: -98 dBm @ 10-6 BER
345 kbps: -106 dBm @ 10-6 BER
15+ miles pt-pt with high gain directional antennas and RF
line-of-sight (Americas version)
Extruded aluminum with DIN and panel mount
117 x 112 x 41 mm / 4.6 x 4.4 x 1.6 inches (W x H x D)
10/100 Base-T connector, shielded RJ45
IEEE 802.3, 802.3u, 802.3x
RS-232, DB9/ RS-422 and RS-485
300 bps to 230 kbps
(1) RP-SMA connector
1.0 lbs (454 g)
-40°F to 149°F (–40°C to +65°C)
Up to100% RH, with no condensation
IEC 60068-2-6 (20g, 3-axis)
IEC 60068-2-27 (5g, 10 Hz to 150 Hz)
9 Vdc to 24 Vdc
12 W peak
