Guide To The Rlx-Ifhe User Manual - ProSoft Technology RadioLinx RLX-IFH E Series User Manual

RLX-IFHE ♦ RadioLinx Industrial Wireless
RadioLinx® Industrial Frequency Hopping Ethernet Radios

Guide to the RLX-IFHE User Manual

Function
Introduction
(Must Do)
Configuring the Radios
Installing the Radios
Diagnostic and
Troubleshooting
Reference
Physical Installation
Antenna Selection
Glossary
Support, Service, and
Warranty
Index
ProSoft Technology, Inc.
November 19, 2013
Section to Read Details
Start Here (page 12) This section introduces the customer to the
module. Included are: package contents,
system requirements, hardware installation, and
basic configuration.
Set Up the Network This section describes the procedure for
(page 24) designing and configuring a network of RLX-
IFHE radios.
Set Up the Master
Radio (page 35)
Add Remote Radios
and Repeaters
(page 40)
Save the Radio
Configuration (page
39)
Radio Hardware This section describes how to install the radio
(page 56) hardware, connect antennas, and connect the
radios to networked devices.
Connecting
antennas (page 56)
Connecting Radios
to a Device Network
(page 58)
Verify This section describes how to verify
Communication communications with the network. Diagnostic
(page 50) and Troubleshooting procedures.
Diagnostics and
Troubleshooting
(page 67, page 68)
Reference (page 79) These sections contain general references
associated with this product, Specifications, and
Product
the Functional Overview.
Specifications (page
13)
Support, Service This section contains Support, Service and
and Warranty (page Warranty information.
99)
Index of chapters.
Guide to the RLX-IFHE User Manual
User Manual
Page 11 of 109
