Northern Telecom BCS35 Replacement Manual page 92

76 Disk Interface circuit pack
Table 8–3xxx
Disk interface PCA (A11 and B11) options – part number: NT6M66AH; 380–Mbyte,
Device Setting
Jumper
(A) In
Strap None used
Rotary None Used
Switch
Table 8–4xxx
Disk interface PCA (A11 and B11) option references – part number: NT6M66AL; 72–Mbyte
and 140–Mbyte, w/o 56K polling
Device Setting
Jumper
(A) In
Strap None used
Rotary None Used
Switch
297-1001-536 Standard 01.03 August 1996
Enable disk Port Interrupt
Enable disk Port Interrupt
Device Setting
Jumper Watchdog timer reset
(R) In
DIP None Used
Switch
Switch None Used
Device Setting
Jumper Watchdog timer reset
(R) In
DIP None Used
Switch
Switch None Used
