Northern Telecom BCS35 Replacement Manual page 69

Table 6–1
QSIO circuit pack (A6 and B6) options – part number: NT6M60AA
Device type
(number)
Rotary 0 50
Switch 1 75/1200
(S5) 2 110
3 134.5
4 150/2400
5 300/4800
6 600/9600
7 1200
Rotary 0 50
Switch 1 75/1200
(S7) 2 110
3 134.5
4 150/2400
5 300/4800
6 600/9600
7 1200
Rotary 0 50
Switch 1 75/1200
(S6) 2 110
3 134.5
4 150/2400
5 300/4800
6 600/9600
7 1200
Switch None used
Notes:
Note 1: See Figure 6–1.
Note 2: This circuit pack does not support polling on digital data lines; use for an analog network only.
Note 3: The MMI Link (DPP to DMS–100 two–way communication channel connected to connector J2 is MMI Link 1.
Note 4: The MMI Link (DPP to DMS–100 two–way communication channel connected to connector J3 is MMI Link 2.
Note 5: Listed for reference only; not supported in software.
Position/setting
8 1800
9 2000
A 2400
B 3600
C 4800
D 7200
E 9600
F 19200
8 1800
9 2000
A 2400
B 3600
C 4800
D 7200
E 9600
F 19200
8 1800
9 2000
A 2400
B 3600
C 4800
D 7200
E 9600
F 19200
Function
IOC Link (MMI Link to
DMS–100) (Asynchro-
nous channel;
baud) Channel B baud
rate select. (Odd num-
bers appear as dashes
on the face of the rotary
3
switch.)
IOC Link (MMI Link to
DMS–100) (Asynchro-
nous channel;
baud) Channel C baud
rate select. (Odd num-
bers appear as dashes
on the face of the rotary
4
switch.)
Local Printer – (Asynch-
ronous channel; 2400
baud) Channel D baud
rate select. (Odd num-
bers appear as dashes
on the face of the rotary
switch.)
5
End
DPP Card Replacement Guide BCS35 and up
QSIO circuit pack 53
(continued)
Setting
Factory On–site
A
(2400
2400 baud)
A
(2400
2400 baud)
A
(2400
baud)
(Rover
terminal;
typically
not
used)
