Northern Telecom BCS35 Replacement Manual page 107

Table 10–3
Data stream interface (DSI) circuit packs (A13 and B13) options – part number: NT6M70AA
and NT6M70CF
Device type
(number)
Strap None used
DIP
Switch
(S1)
DIP
Switch
(S2)
Rotary None used
Switch
Switch None used
Jumper None used
Notes:
Note: See Figure 10–1.
Note: There are no customer–definable options on this circuit packs. Information is shown for reference purposes only. This
data is to be used for verification during initial DPP system installation and/or circuit packs replacement to make certain that
the replacement circuit packs is set–up the same as the circuit packs being replaced.
Position/setting Function
Factory
@S1
6 = On
8 = On
10 = On
1 = Off
2 = Off
3 = Off
4 = Off
5 = Off
7 = Off
9 = Off
@S2
1 = On
4 = On
2 = Off
3 = Off
DPP Card Replacement Guide BCS35 and up
DSI circuit pack 91
Setting
On–site
Must be the
same as
the factory
setting.
