Northern Telecom BCS35 Replacement Manual page 116

100 Replacing bus terminator circuit pack
Procedure 11–2
Replacing bus terminator circuit pack – models H01 and later
( H02 or I01, for example),
Step
18
19
20
21
22
297-1001-536 Standard 01.03 August 1996
Description
Reattach the DSI cables.
Apply power to the chassis.
Wait for start–up activity to end and
the message "S/W loaded." Set the
DPP ONLY processor to PRIME
mode.
If alarm status shows active alarms,
troubleshoot all alarm conditions .
At the maintenance terminal, enter:
TEST ACT (cr)
TEST STDBY (cr)
Reinstall the front chassis on the DPP.
Notes
Set the O/P selector switch to
P. Turn the mode insert key
o
45 to the right and release.
End
