Figure 2–1
CPU with DMA (A1 and B1) circuit pack (NT6M62BA) options
JU3
( )
Note: Switch SW2 is a four–position right angle dip switch at the edge of the
CPU circuit pack.
( )
( )
JU1
JU4
DPP Card Replacement Guide BCS35 and up
CPU circuit pack
LED Display
( )
SW1
SW2
P2
JU2
11
