Northern Telecom BCS35 Replacement Manual page 89

Table 8–2
Disk interface circuit pack (A11 and B11) options – part number: NT6M66AH; 380–Mbyte disk
drives, DPP systems w/o 56K polling
Device type
(number)
Jumper In = Enable disk Port
(A)
Out = Disable disk Port
Jumper Watchdog timer reset
(R)
Strap None used
DIP None used
Switch
Rotary None used
Switch
Switch None used
Notes:
Note 1: See Figure 8–1.
Note 2: There are no customer–definable options on this circuit pack. Information is shown for reference only.
Note 3: Use this data for verification during initial DPP system installation and/or circuit pack replacement to make sure the
replacement circuit pack is set up the same as the circuit pack being replaced.
Position/setting
interrupt
interrupt
Disk Interface circuit pack 73
Function
DPP Card Replacement Guide BCS35 and up
Setting
Factory On–site
Same
as
factory.
Same
as
factory.
