Northern Telecom BCS35 Replacement Manual page 168

152 Four–channel communication circuit pack
Table 16–1
Four–channel communications circuit pack (A17) options – part number: NT6M85AA
Device type
(number)
Jumper
(J6)
Jumper
(J7)
Jumper
(J8)
Jumper
(J9)
Jumper
(J10)
Strap
DIP
Switch
Rotary
Switch
Switch
297-1001-536 Standard 01.03 August 1996
Position/setting
2–3
1–2
2–3
1–2
2–3
1–2
2–3
1–2
2–3
1–2
None used
None used
None used
None used
*Note: ADU operation is not used on the DPP .
Function
ADU Operation*
No ADU operation
(EIA on chan 1 &2)
ADU Operation*
No ADU operation
(EIA on chan 1 &2)
ADU Operation*
No ADU operation
(EIA on chan 1 &2)
ADU Operation*
No ADU operation
(EIA on chan 1 &2)
ADU Operation*
No ADU operation
(EIA on chan 1 &2)
End
Setting
Factory On–site
1–2 Must be
same as
factory
setting.
1–2 Must be
same as
factory
setting.
1–2 Must be
same as
factory
setting.
1–2 Must be
same as
factory
setting.
1–2 Must be
same as
factory
setting.
