Table 10–4
Data stream interface (DSI) circuit packs (A13 and B13) options – part number: NT6M70AC
Device type Position/setting
(number)
DIP (X = On)
Switch
(S2)
Rotary None used
Switch
Switch None used
Jumper All out
Notes:
Note 1: There are no customer–definable options on this circuit packs. Information is shown for reference only. Use this
data for verification during initial DPP system installation and/or circuit packs replacement to make sure the replacement
circuit packs are set up the same as the circuit packs being replaced.
Note 2: U52 is typically not equipped. Strapping is shown for reference only. Factory settings for straps S1–8 and S1–9
subject to change based on availability of EPROM and RAM. Check the manufacturer's identification of U52, U41, and U42
to verify these settings.
Function
End
DPP Card Replacement Guide BCS35 and up
DSI circuit pack 93
Setting
Factory On–site
@S2
1 = On Must be the
4 = On same as
the factory
2 = Off setting.
3 = Off
