UG-044
Qty Reference Designator
3 LK1, LK6, LK9
3 LK3, LK5, LK7
1 U1
1 U2
2 LK2, LK3
1 DI
1 D1
1 D2
11 RXD, RE, DE, DI, A, B, Z, Y,
VDD, GND1,GND2

RELATED LINKS

Resource Description
ADM2587E 500 kbps, 2.5 kV rms signal and power isolated RS-485/RS-422 transceivers with ±15 kV ESD protection
ADM2582E 16 Mbps, 2.5 kV rms signal and power Isolated RS-485/RS-422 transceivers with ±15 kV ESD protection
AN-1349 Application Note, PCB Implementation Guidelines to Minimize Radiated Emissions on the
Transceivers
AN-960 Application Note, RS-485/RS-422 Circuit Implementation Guide
AN-1109
Application Note, Recommendations for Control of Radiated Emissions with iCoupler Devices
AN-0971
Application Note, Control of Radiated Emissions with isoPower Devices
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
EVAL-ADM2582EEBZ/EVAL-ADM2587EEBZ User Guide
Description
6-pin (3 × 2), 2.54 mm header and shorting blocks
2-pin (1 × 2), 2.54 mm header and shorting blocks
20-lead, wide body SOIC
Adjustable voltage regulator
Ferrite beads, 0402
SMA, right hand jack
LED, SMD
Schottky diode, 1 A, SMB
Test points, yellow
Rev. D | Page 12 of 13
Manufacturer Part Number
Harwin M20-9983646 and M7566-05
Harwin M20-9990246
Analog Devices ADM2587EBRWZ
Analog Devices ADP667ARZ
Taiyo Yuden BKH1005LM182-T
TE Connectivity 5-1814400-1
Avago HSMS-C191
ON Semiconductor MBRS130T3G
Vero 20-313140
ADM2582E/ADM2587E RS-485/RS-422
