E2S BExBGL2D-P Instruction Manual page 2

3. Marking & Rating Information
The BExBGl2D-P comply with the following standards for hazardous
locations:
3.1 ATEX / IECEx & UKEx Ratings
Standards
EN60079-0:2018/IEC60079-0:2017
Atmospheres - Equipment General Requirements.
EN60079-1:2014/IEC60079-1:2014
Atmospheres - Equipment Protection by Flameproof Enclosures
"d".
EN60079-31:2014/IEC60079-31:2013
Atmospheres - Equipment Dust Ignition Protection by enclosure
"t".
Model No:
BExBGl2D-P Ex db IIC T6 Gb Ta. -50 to +60°C
Ex db IIC T5 Gb Ta. -50 to +70°C
Ex tb IIIC T60°C Db Ta. -50 to +40°C
Ex tb IIIC T75°C Db Ta. -50 to +55°C
Ex tb IIIC T90°C Db Ta. -50 to +70°C
See Product table for electrical ratings of each unit model
Certificate No. KEMA 00ATEX2006X
IECEx KEM 10.0002X
UL22UKEX2636X
Epsilon x
Equipment Group
and Category:
CE Marking and
Notified Body No.
UKCA Marking and
Approval Body No.
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
Document No. D210-00-401-IS
(ed.7): Explosive
(ed.7): Explosive
(ed.2): Explosive
Rating
II 2G
II 2D
2813
0518
Issue 6 12-09-2022
4. Zones, Gas Group, Category and
Temperature Classification
The units can be installed in locations with the following conditions:
Area Classification Gas
Explosive gas air mixture likely to occur in normal
Zone 1
operation.
Explosive gas air mixture not likely to occur in
Zone 2 normal operation, and if it does, it will only exist for
a short time.
Gas Groupings
Group IIA Propane
Group IIB Ethylene
Group IIC Hydrogen and Acetylene (up to 55°C ambient)
Temperature Classification for Gas Applications
o
T1 450 C
T2 300 o C
T3 200 o C
o
T4 135 C
T5 100° C
T6 100° C (Up to +60°C Ambient)
Area Classification Dust
Explosive dust air mixture likely to occur in normal
Zone 21
operation.
Explosive dust air mixture not likely to occur in
Zone 22 normal operation, and if it does, it will only exist for
a short time.
Dust Groupings
Group IIIA Combustible Dusts
Group IIIB Non-Conductive Dusts
Group IIIC Conductive Dusts
Equipment Category
2G, 2D
Equipment Protection Level
Gb, Db,
Maximum Surface Temperature for Dust Applications
60°C at +40°C
75°C at +55°C
90°C at +70°C
Ambient Temperature Range
-50°C to +70°C Gas Groups IIA, IIB and IIC
-50°C to +70°C Dust Groups IIIA, IIIB and IIIC
IP66/67 to EN/IEC60529 and
IP6X to EN/IEC60079-0, EN/IEC60079-31
The beacon must only be installed by suitably qualified personnel in
accordance with the latest issues of the relevant standards:
EN60079-14 / IEC60079-14: Explosive atmospheres - Electrical
installations design, selection and erection
EN60079-10-1 / IEC60079-10-1:
Classification of areas. Explosive gas atmospheres
EN60079-10-2 / IEC60079-10-2:
Classification of areas. Explosive dust atmospheres
The installation of the beacon must also be in accordance with any local
codes that may apply and should only be carried out by a competent
electrical engineer who has the necessary training.
www.e2s.com
IP Rating
Explosive atmospheres
Explosive atmospheres
Tel: +44 (0)208 743 8880
Sheet 2 of 6
-
-
