- Page 1 CV–4 COVE 4-PERSON OPEN-PANEL MEETING POD *General Guide | See Master Plan Instructions in English and en Español...
- Page 3 1 | MEASURE TO APPROXIMATE WIDTH 85 ” 78.7 ” Measure from the outer edge of the pod or from the inner wall of the pod to find the approximate width. Once positioned, roof panel may be installed. Alinee los levantadores para que estén al ras con los agujeros de unión en el panel adyacente. Empuje contra las paredes exteriores de el booth hasta que los paneles estén al ras.
- Page 4 3 | CONNECT MAIN POWER Assemble the connector joint by securing the male and female halves together and securing with connector clips to the top and bottom of the assembly. Ensamble la unión del conector asegurando las mitades masculinas y femeninas juntas y asegurelas con los clips conectadores en la parte superior e inferior del conjunto.
- Page 5 5 | SECURE TOP PANEL Line up steel dowels so they are flush with the joint holes on the adjacent panel. Push against the outer walls of the booth until panels are flush. Alinee los levantadores para que estén al ras con los agujeros de unión en el panel adyacente. Empuje contra las paredes exteriores de el booth hasta que los paneles estén al ras.
- Page 6 7 | PLACE SEATS INSIDE BOOTH Tilt seat at a 45 degree angle. Slide into the COVE booth while tilting the seat back so that the seat sits flat on the floor. Incline el asiento en un ángulo de 45 grados. Deslíze el asiente dentro del booth COVE mientras inclinas el respaldo para que el asiento quede plano en el piso.
- Page 8 210.648.2095 | mycleardesign.com © 2020 Clear Design. All rights reserved.
