SPECIFICATIONS (1 OF 2)

MAGNUM MODEL
Engine
Make/Brand................................................................... Isuzu .............................................Isuzu
Model ............................................................................ 4LE1NYGV-01 ..............................4LE1NYGV-03G
...................................................................................... 4LE1NYGV-03E
EPA Tier ........................................................................ 4i ...................................................4i
Horsepower - prime hp (kW) ....................................... 32.1 (23.9) ....................................32.1 (23.9)
Horsepower - standby hp (kW) .................................... 35.3 (26.3) ....................................35.3 (26.3)
Operating Speed rpm .................................................. 1800..............................................1800
Displacement in 3 (L) .................................................... 134 (2.2) .......................................134 (2.2)
Cylinders - qty ............................................................... 4....................................................4
Fuel Consumption - 100% prime gph (Lph) ................ 1.80 (6.81) ....................................1.80 (6.81)
Battery Type - Group Number ....................................... 24..................................................24
Battery Voltage (Quantity per Unit) ............................... 12V (1) ..........................................12V (1)
Battery Rating ............................................................... 720 CCA .......................................720 CCA
Generator
Make/Brand................................................................... Marathon Electric..........................Marathon Electric
Model ............................................................................ 282NSL1505.................................282NSL1505
Type, Insulation ............................................................. Brushless, H .................................Brushless, H
Generator Set (Engine/Generator)
3Ø - Standby kW (kVA) ............................................... 20 (25) ..........................................20 (25)
Amps - 3Ø Standby - 480V (208V) A ............................ 30 (69) ..........................................30 (69)
3Ø - Prime kW (kVA) ................................................... 18 (23) ..........................................18 (23)
Amps - 3Ø Prime - 480V (208V) A................................ 28 (64) ..........................................28 (64)
1Ø - Standby kW (kVA) ............................................... 16.0 (16.0) ....................................16.0 (16.0)
Amps - 1Ø Standby - 240V A........................................ 67..................................................67
1Ø - Prime kW (kVA) ................................................... 15.0 (15.0) ....................................15.0 (15.0)
Amps - 1Ø Prime - 240V A............................................ 63..................................................63
Frequency Hz ............................................................... 60..................................................60
Power Factor................................................................. 1 (1Ø), 0.8 (3Ø) ............................1 (1Ø), 0.8 (3Ø)
Pump
Make/Model ................................................................. SHURFlo.......................................SHURFlo
Flow Rate gpm (Lpm) ................................................. 3.3 (12.5) ......................................3.3 (12.5)
Flow Rate at Hose Bibb gpm (Lpm) ............................ 3.0 (11.4).......................................3.0 (11.4)
Weights
Dry Weight lbs (kg) ...................................................... 5220 (2368) ..................................5220 (2368)
Operating Weight lbs (kg) ........................................... 10960 (4971) ................................10960 (4971)
Capacities
Fuel Tank Volume gal (L) ............................................. 246 (931) ......................................246 (931)
Usable Fuel Volume gal (L) ......................................... 229 (867) ......................................229 (867)
Water Tank Volume gal (L) .......................................... 500 (1895) ....................................500 (1895)
Maximum Run Time hrs .............................................. 127................................................127
Lighting
Lighting Type................................................................. Metal Halide..................................Metal Halide
Ballast Type................................................................... Coil & Core ...................................Coil & Core
Lumens ......................................................................... 440,000.........................................440,000
2 ) ................................................... 5 - 7 (20,234 - 28,328) ..................5 - 7 (20,234 - 28.328)
Coverage acres (m
AC Distribution
Circuit Breaker Size ...................................................... 90..................................................90
Voltage Selection .......................................................... 3 Position Switch (lockable)..........3 Position Switch (lockable)
Voltage Regulation........................................................ +/-1% ............................................+/-1%
Voltages Available 1Ø ................................................... 120, 139, 208, 220, 240, 277........120, 139, 208, 220, 240, 277
Voltages Available 3Ø ................................................... 208, 220, 440, 480........................208, 220, 440, 480
Specifications are subject to change without notice.
10
MTT25 MTT25CAN
