Specifications; Fuel Requirements; Engine Oil Requirements; Generator Specifications - Generac Power Systems NP-66LPG Series Owner's Manual

Generac NP-66LPG Recreational Vehicle Generator
FUEL REQUIREMENTS
The "NP" series generator is equipped with a liquefied petro¬
leum (LP) gas fuel system. LP gas is usually supplied as a
liquid in pressure tanks.
"NP" series generators require a "vapor withdrawal" type fuel
system. This type of gaseous fuel system uses the vapors form¬
ing above the liquid fuel in the storage tank. Air temperature
around the storage tank must be high enough to sustain ade¬
quate fuel vaporization. In colder climates, you may need to
use an independent heat source to be sure the fuel suffi-
cently vaporizes in the storage tank.
LP gas may consist of propane, butane or mixture of two
gases. Propane vaporizes at temperatures as low as -20° F
(-29°C), but butane returns to its liquid state when the tem-
perture drops below about 32°F (0°C). For that reason, a
higher ratio of propane is desired in the gas mixture when tem¬
peratures drop below freezing.
ENGINE OIL REQUIREMENTS
Use a high quality detergent oil classified "For Service SP and
with an oil viscosity rating of SAE10W-30 oil. Do not pour in
any additives to the recommended oil. Engine crankcase
capacity is 1.5 U.S. quarts (1.4 liters). See MAINTENANCE
section for oil level check and filing procedures.
ENGINE SPECIFICATIONS
Type of Engine.
Cooling Method.
Rated Horsepower.
Displacement.
Compression Ratio.
Cylinder Block.
Type of Governor.
Engine Governed Speed.
Air Cleaner.
Starter.
Ignition System.
Recommended Spark Plugs
Champion.
AC.
Fram Autolite.
Spark Plug Gap.
.Twin Cylinder
.Air-cooled
.,.16 at 3600 rpm
...479.4cc
.8.6 tol
.Aluminum with cast
iron sleeve
....Mechanical, fixed
speed
.See chart above
.Paper element with
foam pre-cleaner
.12 volts DC electric
.Solid state with
flywheel magneto
.RC12YC
..R45S
..65
.0.030 inch (0.8mm)
GENERATOR SPECIFICATIONS
Rotor RPM. 3600
Rotor Poles...'.2
Engine RPM.2700
Rated Maximum Continuous
AC Output.6600 watts (6.6 kw)
Voltage.120 volts*
Rated Maximum Continuous AC Current.55 amperes
Phase.single
Frequency.1.60 Hertz
Weight.213 pounds
Length.25 inches
Width.18.5 inches
Height.15.75 inches
* The unit is reconnectable to 120 and/or 240 volts, dual voltage
output.
Rated maximum continous current at 240 volts is 27.5 amps.
Recreational Vehicle Generalor
12
