SHUTTING DOWN THE UNIT

Check with personnel using power supplied by the unit and let them know the power is going to be turned off. Make
sure the power shut down will not create any hazards by accidentally turning off equipment that needs to be kept on
(pumps, compressors, lights, etc.).
When you have finished using the unit, proceed with shut down as follows:
1. Remove any loads from the generator output connection lugs and receptacle panel.
2. Switch the individual circuit breakers for each light (A) to the OFF (O) position.
3. Switch the generator main circuit breaker and receptacle panel main circuit breaker (B) to the OFF (O) position.
4. Push ENGINE STOP (C). Pressing the red Engine Stop button will result in the unit going into the shutdown
cycle and starting a 15 second shutdown timer called stop value. If the unit does not shut down within 15 seconds,
a stop fail alarm will be displayed on the Liquid Crystal Display (LCD) window.
5. Turn the Control Power switch (D) to the OFF (O) position.
Always switch all circuit breakers to the OFF (O) position to prevent starting the generator
NEUTRAL BONDED TO FRAME
NULL-LEITER AM RAHMEN ANGESCHLOSSEN
CONDUCTOR NEUTRO CONECTADO AL CHASIS
CONDUCTEUR NEUTRE MIS A LA MASSE DU CHASSIS
GENERATOR
MAIN
CIRCUIT
BREAKER
Note: For extended storage time, disconnect the battery. For extended storage requirements, refer to the engine
operator's manual.

USING THE WATER SUPPLY

NEVER use water in the supply tank for human consumption, even if the water is potable.
The tank is made to store water for washing or domestic purposes only, drinking water from
The unit comes equipped with a 500 gallon (1,895 L) water tank and a manifold with four hose bibbs. This allows
the water tank to be connected to a trailer or RV for water to be used in non-potable applications. Two bibbs are for
gravity feed only and two bibbs are pressurized by the onboard pump; the pump only operates when the engine is
running.
34
A
B
LIGHTS AND
RECEPTACLE
PANEL 1 2
MAIN
CIRCUIT
BREAKER
3 4
the tank could result in immediate or long term harm.
CAUTION
under load.
CAUTION
C D
