Specifications; Generator; Engine - Generac Power Systems 15 kW EcoGen Owner's Manual

General Information
2.5 — Specifications
2.5.1— Generator
Model
Rated Voltage
Rated Maximum Load
Current (Amps) at 240 Volts (LP)*
Main Circuit Breaker
Phase
Rated AC Frequency
Battery Requirement
Unit Weight in Lbs. (kilos)
Enclosure
Normal Operating Range
These generators are rated in accordance with UL 2200, Safety Standard for Stationary Engine Generator Assemblies, and CSA-
C22.2 No. 100-04
Standard for Motors and Generators.
* Natural Gas ratings will depend on specific fuel Btu/joules content. Typical derates are between 10-20% off the LP gas rating.
2.5.2— Engine
Model
Type of Engine
Number of Cylinders
Displacement
Cylinder Block
Recommended Spark Plug
Spark Plug Gap
Starter
Oil Capacity Including Filter
Recommended Oil Filter
Recommended Air Filter
Maximum wattage and current is subject to and limited by such factors as fuel Btu/joules content, ambient temperature and alti-
tude. Maximum power decreases about 3.5 percent for each 1,000 feet (304.8 meters) above sea level, and also will decrease
about 1 percent for each 6º C (10º F) above 15º C (60º F) ambient temperature.
The specification sheet for this generator was included in the documentation provided with the unit at the time of pur-
chase. For additional copies, consult your local Authorized Independent Service Dealer.
8
Group 26R, 12 Volts and 525 CCA Minimum (Generac Part No. 0H3421S)
This unit is tested in accordance to UL 2200 standards with an operating temperature of
-20º F (-29º C) to 122º F (50º C). For areas where temperatures fall below 32º F (0º C) a
cold weather kit is required. When operated above 77º F (25º C) there may be a decrease in
engine power. Please reference the engine specifications section.
Approx. 3.75 Quarts / 3.55 Liters
15 kW EcoGen
240
62.5
65 Amp
1
60 Hz
536 (243)
Aluminum
15 kW EcoGen
GT-999
2
999 cc
Aluminum w/Cast Iron Sleeve
RC12YC
1.02 mm (0.040 in)
12 VDC
Part #070185E
Part #0J8478
EcoGen Automatic Standby Generator Owner's Manual
