Specifications; Generator; Engine - Generac Power Systems 7.5 kW PowerPact Owner's Manual

General Information

Specifications

Generator

Model
Rated voltage
Rated maximum load current
(amps) at rated volts (LP)*
Main line circuit breaker
(generator disconnect)
Phase
Rated AC frequency
Battery requirement
Enclosure
Unit weight
Normal operating range
These generators are rated in accordance with UL 2200, Safety Standard for Stationary Engine Generator Assemblies, and CSA-
C22.2 No. 100-04 Standard for Motors and Generators.
* Natural Gas ratings will depend on specific fuel joules/Btu content. Typical derates are between 10-20% off the LP gas rating.
** Circuits to be moved must be protected by same size breaker. For example, a 15 amp circuit in the main panel must be a 15 amp
circuit in the transfer switch.

Engine

Model
Engine type
Number of cylinders
Displacement
Cylinder block
Recommended spark plug
Spark plug gap
Valve clearance
Starter
Oil capacity
Recommended air filter
Engine power is subject to and limited by such factors as fuel Btu/joules, ambient temperature and altitude. Engine power decreases
about 3.5 percent for each 1000 feet (304.8 meters) above sea level, and also will decrease about 1 percent for each 10 °F (6 ºC) above
60 ºF (15 ºC) ambient temperature.
A detailed specification sheet for a particular generator is available from an IASD.
8
Group U1, 12 Volts and 300 CCA Minimum (see
This unit is tested in accordance to UL 2200 standards with an operating temperature of -20
ºF (-29 ºC) to 122 ºF (50 ºC). For areas where temperatures fall below 32 ºF (0 ºC) a cold
weather kit is recommended. When operated above 77 ºF (25 ºC) there may be a decrease
in engine power. (Please reference the engine specifications section.)
7.5 kW
240
31.25
35 Amp
1
60 Hz
Galvanneal steel
280 lbs (127.3 kg)
7.5 kW
GA-420
1
3
25.6 in (420 cc)
Aluminum w/ cast iron sleeve
See
Replacement Parts
0.030 in (0.76 mm)
0.002 - 0.004 in (0.05 - 0.1 mm)
12 VDC
Approx. 1.2 qt (1.1 L)
See
Replacement Parts
Owner's Manual for 7.5 kW PowerPact™
Replacement Parts)
