TO USE THE PRESSURIZED WATER SUPPLY BIBB(S):
1. Connect a hose from one of the pressure hose bibbs
to the end location (trailer, RV, etc.).
2. Start the engine on the unit.
3. Switch the main circuit breaker to the ON (I) position.
4. Open the pressure hose bibb(s).
5. Switch the pump on; it will stop automatically when
the water pressure reaches 35 psi (241 kPa).
TO USE THE GRAVITY WATER SUPPLY BIBB(S):
1. Connect a hose from one of the gravity hose bibbs
to the end location.
2. Open the gravity hose bibb(s).
Drain the tank when the temperature is expected to drop below 32°F (0°C) or if the unit is
TO REFILL THE WATER TANK:
1. Close all hose bibbs.
2. Remove the tank cover; leave the smaller inspection cap in the center of the cover in place.
3. Fill the tank from a water source.

LOWERING THE MAST - MANUAL

1. Shut down the lights and engine, refer to
minutes before lowering the mast.
2. If the unit is going to be moved, it is recommended that the mast is turned so the lights face the rear of the unit.
To rotate the mast:
A. Loosen the mast rotation knob.
B. Rotate the mast until the white arrows are aligned and the metal stop tabs are touching.
C. Tighten the mast rotation knob.
Note: For transportation, Magnum Power Products LLC strongly recommends the lights be removed from the mast
and stowed. Refer to "Removing the Lights for Transportation" on page
3. Turn the upper mast winch handle counterclockwise to collapse the mast to its lowest position. Ensure the
electrical cord does not get caught in, or pinched by, the mast while it is being lowered.
STOP IMMEDIATELY if the mast hangs up or the winch cable begins to develop slack.
Excess slack in the cable could cause the mast to collapse, which could result in personal
injury or equipment damage. Contact an authorized service center.
to be stored for a long period of time.
"Shutting Down the Unit" on page
CAUTION
Pressure
Gravity
Bibbs
Bibbs
Pump
Switch
34. Allow the lights to cool 10-15
37.
00229
35
