Digital Watchdog MEGApix DWC-MB45WiAT User Manual page 45

Setup - Event setup
Motion detection configuration
1
2
3
4
5
Motion Detection - When the camera detects motion, it will show the motion detection icon in orange on the camera's view.
1
Event alert icon( ) appears if 'motion detection' is activated.
Area - Set the motion detected area. Select an area from the drop-down list. Using the mouse, click and drag to mark the size and
2
position of the motion detection zone. You can setup 4 separate zones.
Activation - Enable or disable motion detection function.
3
Sensitivity - Define the sensitivity of motion detection.
4
If high is selected, the camera will detect very small motion. If low is selected, the camera will detect only large motion events in its view.
Click 'Save' to save the current settings.
5
Click 'Cancel' to return to the previous setting.
45
