Web viewer screen -
Basic screen
2
3
4
5
Web viewer is optimized with IE10 or higher and Firefox.
If VLC is not installed or the VLC plugin is not supported (Chrome), live buffering and channel select menu will change to the
live viewer menu. If VLC is not installed or updated, you can select HTML5(MJPEG) is under live viewer menu to view live
video.
Live video display. This is the region for live video stream from the camera.
1
Setup button. Open the setup page to setup the camera's video, network, events and system settings.
2
See section 'setup' for more information.
When the image is choppy due to a bad network connection, you can adjust the buffering settings.
3
User will see the delayed images as much as setup time.
Channel Select button. Select a stream produced from the camera between Stream 1 ~ 3 to display it in the live view screen.
4
Refer 'setup > Video & Audio > Video' to setup the Video Stream.
Below menu options may vary based on the camera's model.
5
PTZ control - Control the camera's zoom and focus remotely.
Preset - Not supported.
Speaker control - Enable/disable the audio stream from the camera and adjust the volume as needed.
Alarm input - If an alarm is triggered, the alarm number on the input panel will change to bright orange.
Relay output - Use the checkbox to manually activate the camera's relay output or view its status in case of an event.
Motion - When the camera detects motion, an indicator will appear on the camera's main view.
6
Event alert icon ( ) appears if 'motion detection' is activated in the camera's settings.
Camera Time - Displays the camera's local time.
7
13
1
6
7
