Digital Watchdog MEGApix DWC-MB45WiAT User Manual page 35

Setup - Network setup
FTP settings
1
2
3
4
5
6
7
To send and save images from the camera to an FTP server, an FTP needs to be setup.
General setting - Enable or disable the FTP function.
1
FTP server address - Enter the FTP server's IP Address. If the IP address is incorrect, a message box will appear.
2
FTP upload path - Enter the path in the FTP server where the video from the camera will be stored. For the path name,
3
English alphabets, numbers and special characters ( / ~ !@ $ ^ ( ) _ - { } [ ] ; , ) can be used.
FTP port - Enter the FTP server's port. If the port value is incorrect, the camera cannot access FTP server.
4
User ID - Enter User ID to access the FTP server.
5
Password - Enter the password to access the FTP server.
6
Click 'Apply' to make above setting effective.
7
Refer the above screen image for the example.
35
