Setup - Trigger action setup
Relay out configuration
1
2
3
4
5
Relay output - Select the relay output.
1
The number of relay outputs depends on the camera model.
Mode - Select the monostable / bistable for relay mode.
2
Idle state - Select whether the contact is normally opened or is closed.
3
Duration - Relay out is operated during the setting time.
4
If bistable mode is selected, this function is active.
Click 'Apply' to make above setting effective.
5
