Digital Watchdog MEGApix DWC-MB45WiAT User Manual page 30

Setup - Network setup
Network settings
1
2
3
4
5
6
7
8
9
10
Network type - Set the camera's network type. Select Dynamic or Static IP.
1
Static mode allows you to manually enter the camera's network information, including IP address, subnet mask, gateway, DNS
Server and all ports.
Dynamic mode allows the camera to get its network settings automatically from the network it is connected to.
If you click the Apply button to update changes, the system will be re-booted.
In this case, you have to reconnect the camera using new IP address.
IP address - Enter the camera's IP address. The address is consisted of four numbers separated by dots and the range of
2
each number is from 0 to 255.
Subnet mask - Enter the subnet mask. Format is the same as the IP address.
3
Default gateway - Enter the gateway's IP address. Format is the same as the IP address.
4
Preferred DNS server - Enter the DNS server's IP address. Format is the same as the IP address.
5
Alternate DNS server - Enter the secondary DNS server's IP address, if needed. Format is same as the IP address.
6
HTTP port - The HTTP port can be set to 80 (default) or any value between 1025 to 60000.
7
HTTPS port - The HTTPS port can be set to 443 (default) or any value between1025 to 60000.
8
RTSP port - The RTSP port can be set to 554 (default) or any value between 1025 to 60000.
9
Click 'Apply' to make above setting effective.
10
If the network type is dynamic, all the network settings will be changed automatically to match the settings
of the current network. The IP address will change every time the camera power cycles, new firmware is
installed, or the camera is reset to factory settings. In this case, you may need to search of your camera in the
network again and re-add it to your server. Consult your network administrator for more information.
30
