Digital Watchdog MEGApix DWC-MB45WiAT User Manual page 38

Setup - Network setup
RTSP information
1
2
3
4
5
Target stream - Select the stream you want to set.
1
Time out - Set the RTSP time out.
2
The session is disconnected after the specified time out.
RTP Multicast - Check RTP multicast on/off. To activate RTP multicast.
3
1. Click "On" button.
2. Enter accessible RTP multicast IP, port for video stream control, RTP packet TTL.
3. Click "Apply" button.
It is possible to set each RTP multicast for CH1~3.
Click 'Apply' to make above setting effective.
4
Click this button when setup is completed for each channel.
It shows RTSP Connection information.
5
38
