E2S D2xB1X05 Instruction Manual page 2

3.2. ATEX / IECEx / UKEx Ratings
EN IEC 60079-0:2018 / IEC60079-0:2017 (Ed 7):
Explosive Atmospheres - Equipment. General Requirements
EN IEC 60079-7:2015 +A1:2018 / IEC 60079-7:2018 (Ed. 5.1):
Explosive Atmospheres - Equipment Protection by Increased
Safety "e"
EN 60079-31:2014 / IEC 60079-31:2013 (Ed 2):
Explosive Atmospheres - Equipment Dust Ignition Protection by
Enclosure "t"
D2xB1: Ex ec IIC T2 Gc Ta -40°C to +50°C
X05DC024 Ex tc IIIC T80°C Dc Ta -40°C to +50°C
D2xB1: Ex ec IIC T3 Gc Ta -40°C to +50°C
X05DC048 Ex tc IIIC T95°C Dc Ta -40°C to +50°C
X05AC115
X05AC230
D2xB1: Ex ec IIC T1 Gc Ta -40°C to +50°C
X10DC024 Ex tc IIIC T105°C Dc Ta -40°C to +50°C
D2xB1: Ex ec IIC T2 Gc Ta -40°C to +50°C
X10DC048 Ex tc IIIC T95°C Dc Ta -40°C to +50°C
X10AC115
X10AC230
Certificate No.
ATEX Mark, Equipment
Group and Category:
CE Marking
UKCA Marking
3.3. NEC & CEC Ratings
NEC & CEC Class / Division Ratings for US / Canada
UL 121201-2021 (Ed. 9)
CAN/CSA C22.2 No. 213-17 (Ed. 3)
D2xB1: Class I Div 2 ABCD T2D Ta -40°C to +50°C
X05DC024 Class I Div 2 ABCD T3 Ta -40°C to +45°C
Class II Div 2 FG T6 Ta -40°C to +50°C
Class III Div 1&2 Ta -40°C to +50°C
D2xB1: Class I Div 2 ABCD T3 Ta -40°C to +50°C
X05DC048 Class II Div 2 FG T5 Ta -40°C to +50°C
X05AC115 Class II Div 2 FG T6 Ta -40°C to +40°C
X05AC230 Class III Div 1&2 Ta -40°C to +50°C
D2xB1: Class I Div 2 ABCD T1 Ta -40°C to +50°C
X10DC024 Class I Div 2 ABCD T2 Ta -40°C to +45°C
Class II Div 2 FG T4A Ta -40°C to +50°C
Class II Div 2 FG T5 Ta -40°C to +45°C
Class III Div 1&2 Ta -40°C to +50°C
European Safety Systems Ltd. Impress House, Mansell Road, Acton, London W3 7QH
Document No. D211-00-201-IS
Standards
Ratings
DEMKO 14 ATEX 4786493904X
IECEx ULD 14.0004X
UL21UKEX2131X
II 3G
II 3D
Standards
Ratings
Issue 1
D2xB1:
X10DC048
X10AC115
X10AC230
Installation must be carried out in compliance with the National
Electric Code / Canadian Electric Code
NEC Class / Zone ratings US
UL 60079-0 (Ed. 7):
Explosive Atmospheres - part 0: Equipment - General
Requirements
UL 60079-7 (Ed. 5):
Explosive Atmospheres - Equipment Protection by Increased
Safety "e"
UL 60079-31 (Ed. 2)
Explosive Atmospheres - Equipment Dust Ignition Protection by
Enclosure "t"
D2xB1:
X05DC024
D2xB1:
X05DC048
X05AC115
X05AC230
D2xB1:
X10DC024
D2xB1:
X10DC048
X10AC115
X10AC230
Installation must be carried out in compliance with the National
Electric Code.
CEC Class / Zone ratings Canada
CAN/CSA C22.2 No. 60079-0 (Ed. 4) 02/2019
Explosive Atmospheres - Part 0: Equipment - General
Requirements
CAN/CSA C22.2 No. 60079-7 (Ed. 2)
Explosive Atmospheres - Equipment Protection by Increased
Safety "e"
CAN/CSA C22.2 No. 60079-31 (Ed. 2)
Explosive Atmospheres - Equipment Dust Ignition Protection by
Enclosure "t"
D2xB1:
X05DC024
D2xB1:
X10DC024
D2xB1:
X05DC048
X05AC115
X05AC230
20-08-22
Class I Div 2 ABCD T2B Ta -40°C to +50°C
Class II Div 2 FG T5 Ta -40°C to +50°C
Class II Div 2 FG T6 Ta -40°C to +40°C
Class III Div 1&2 Ta -40°C to +50°C
Standards
Ratings
Class I Zone 2 AEx ec IIC T2 Gc Ta -40°C to
+50°C
Zone 22 AEx tc IIIC T80°C Dc Ta -40°C to +50°C
Class I Zone 2 AEx ec IIC T3 Gc Ta -40°C to
+50°C
Zone 22 AEx tc IIIC T95°C Dc Ta -40°C to +50°C
Class I Zone 2 AEx ec IIC T1 Gc Ta -40°C to
+50°C
Zone 22 AEx tc IIIC T105°C Dc Ta -40°C to +50°C
Class I Zone 2 AEx ec IIC T2 Gc Ta -40°C to
+50°C
Zone 22 AEx tc IIIC T95°C Dc Ta -40°C to +50°C
Standards
Rating
Ex ec IIC T2 Gc X Ta -40°C to +50°C
Ex tc IIIC T80°C Dc Ta -40°C to +50°C
Ex ec IIC T1 Gc X Ta -40°C to +50°C
Ex tc IIIC T105°C Dc Ta -40°C to +50°C
Ex ec IIC T3 Gc X Ta -40°C to +50°C
Ex tc IIIC T95°C Dc X Ta -40°C to +50°C
www.e2s.com Tel: +44 (0)208 743 8880
Sheet 2 of 6
