1

OVERVIEW

®
The NuMicro
Family microcontroller (MCU) supports In-System-Programming (ISP) function
allowing the embedded Flash memory to be reprogrammed under software control. ISP is
performed without removing the microcontroller from the system through the firmware and on-chip
connectivity interface, such as UART, USB, I²C, SPI, and CAN.
Before using the ISPTool, user needs to program the ISP code into LDROM by using a universal
programmer or Nuvoton's NuMicro
configured as Boot from LDROM.
ISP code can be found in the board support package (BSP). Take M480BSP for example, we
supplied ISP_CAN, ISP_HID, ISP_HID_20, ISP_I2C, ISP_RS485, ISP_SPI and ISP_UART
samples as shown in the following link.
https://github.com/OpenNuvoton/M480BSP/tree/master/SampleCode/ISP
The ISPTool repository is available on GitHub, GITEE and GitLab.
Please check the following link to get the latest update.
https://github.com/OpenNuvoton/ISPTool
https://gitee.com/OpenNuvoton/ISPTool
https://gitlab.com/OpenNuvoton/nuvoton-tools/ISPTool
Oct. 15, 2019
®
ICP Programming Tool, and the User Configuration bit 'CBS'
Page 3 of 9
ISP Programming Tool
Rev 3.05
