2.6
Programming Options
The following table lists the ISP actions for different programming options.
Programming Options
APROM
Data Flash
Config
Erase All
Reset and Run
Oct. 15, 2019
APROM will be updated.
Data Flash will be updated.
User Configuration will be updated while target chip is
not in write protected mode.
1. User Configuration is in write protected mode when
security lock is enabled.
2. Program APROM or Erase All option can remove
write protection of User Configuration.
Note: Any change on User Configuraion block will take
effect after system reboot.
APROM and Data Flash will be erased.
The Security Lock in User Configuration will be
disabled.
The system reset is issued and the chip is running user
application on APROM.
Table 2-8 ISP Programming Options
Page 8 of 9
ISP Programming Tool
ISP Actions
Rev 3.05
