SECTION 1.
• Frequency coverage
• Type of emission
• Number of programable channels
• Output impedance (audio)
• Input impedance (MIC)
• Operating temperature range
• Power supply requirement
• Current drain
(approximately)
• Dimensions
• Weight (approximately)
• Transmit output power
• Modulation
• Maximum permissible
deviation
• Frequency error
• Spurious emission
• Adjacent channel power
• Audio harmonic distortion
• FM hum and noise
(without CCITT filter)
• Limiting charact of modulation
• Microphone impedance
• Receive system
• Intermediate frequencies
• Sensitivity
• Squelch sensitivity (at threshold)
• Adjacent channel
selectivity
• Spurious response
• Intermodulation
• Hum and Noise
(without CCITT filter)
• Audio output power
All stated specifications are subject to change without notice or obligation.

SPECIFICATIONS

[USA-01]
[EXP-01]
[CHN-01]
[USA-02]
[EXP-02]
[EXP-03]
Wide
Except [USA]
Narrow
Digital
Stand-by
RX
Maximum audio
TX at 45 W
Wide
Narrow
[USA]
[EXP], [CHN]
Wide
Narrow
Digital
Wide
Narrow
Wide
Narrow
Digital
Wide
Narrow
Digital
Wide
Narrow
400–470 MHz
450–512 MHz
450–520 MHz
350–400 MHz
16K0F3E (25.0 kHz)
11K0F3E (15.0 kHz)
8K50F3E (12.5 kHz)
4K00F1E, D (6.25 kHz)
128 channels (8 zones)
4 Ω
600 Ω
–30˚C to +60˚C (−22˚F to +140˚F)
13.6 V DC norminal Negative ground
300 mA (Digital Mode)
1.2 A
11.0 A
150(W)×40(H)×167.5(D) mm; 5.9(W) × 1.6(H) × 6.6(D) in
1.1 kg; 2 Ib 7 oz
45 W
Variable reactance frequency modulation
±5.0 kHz
±2.5 kHz
±1.0 ppm
72 dB minimum 85 dB typical
70 dB minimum 85 dB typical
70 dB minimum 73 dB typical
60 dB minimum 70 dB typical
3% typical (with 1 kHz AF 40% deviation)
40 dB minimum 46 dB typical
34 dB minimum 40 dB typical
70–100% of maximum deviation
2.2 kΩ
Double conversion superheterodyne
1st IF; 46.35 MHz, 2nd IF; 450 kHz
0.25 μV typical at 12 dB SINAD
–8 dBμV (EMF) typical at 5% BER
0.25 μV typical
70 dB minimum 75 dB typical
65 dB minimum 68 dB typical
50 dB minimum 60 dB typical
More than 70 dB
70 dB minimum 75 dB typical
65 dB minimum 70 dB typical
40 dB minimum 46 dB typical
34 dB minimum 40 dB typical
4.0 W typical at 5% distortion with an 4 Ω load
