Icom IC-F6220D Service Manual page 36

SECTION 8.
[CHASSIS PARTS]
REF ORDER
NO. NO.
J1 6510004881 MR-DSE-01-1 <GA>
MP1 8010019138 2601 LONG CHASSIS-8
MP2 8110007821 2601 COVER-1
MP3 8810008661 PHBT M3 X 8 NI-ZC3
MP4 8810008661 PHBT M3 X 8 NI-ZC3
MP5 8810008661 PHBT M3 X 8 NI-ZC3
MP6 8810008661 PHBT M3 X 8 NI-ZC3
MP7 8810009991 PHBT M3 X 8 NI-ZK3
MP8 8810009991 PHBT M3 X 8 NI-ZK3
[MAIN-A UNIT]
REF ORDER
NO. NO.
J1001* 6510014961 B2B-ZR-SM4-TF (LF) (SN)
J1002 6450000140 HSJ0807-01-010
J1003* 6510022891 B13B-ZR-SM4-TF (LF) (SN)
J1004* 6510027960 04-6294-040-000-800+
S1001* 2260003180 MINISMDC050F-2 CN <UDX>
W1 7030012290 RDS2T0R0
W2 8900011863 OPC-1195C
EP4 6910010280 HF70BB9.5X10.4X4.9
EP5 6910010280 HF70BB9.5X10.4X4.9
EP14 6910011560 HF70BB4.5X5X1.6
EP15 6910011560 HF70BB4.5X5X1.6
MP1* 8510019340 3179 VCO CASE Y1142
MP2 8510019350 3179 VCO COVER Y1143
MP3 8510015110 2602 M-PLATE Y660
MP4 8930055841 2490 EARTH SPRING-1
MP5 8510014910 2601 FILTER CASE
MP6 8510020540 3331 B-SHIELD PLATE Y1272
MP7 8930058170 SHIELD SPONGE (O)
MP9 8930059390 SHIELD SPONGE (Y)
MP10 8930083380 3331 AF SHEET (TC-30CG-AV)
[MAIN-B UNIT]
REF ORDER
NO. NO.
J1001* 6510014961 B2B-ZR-SM4-TF (LF) (SN)
J1002 6450000140 HSJ0807-01-010
J1003* 6510022891 B13B-ZR-SM4-TF (LF) (SN)
J1004* 6510027960 04-6294-040-000-800+
S1001* 2260003180 MINISMDC050F-2 CN <UDX>
W1 7030012290 RDS2T0R0
W2 8900011863 OPC-1195C
EP4 6910010280 HF70BB9.5X10.4X4.9
EP5 6910010280 HF70BB9.5X10.4X4.9
MP1* 8510019340 3179 VCO CASE Y1142
MP2 8510019350 3179 VCO COVER Y1143
MP3 8510015110 2602 M-PLATE Y660
MP4 8930055841 2490 EARTH SPRING-1
MP5 8510014910 2601 FILTER CASE
MP6 8510020540 3331 B-SHIELD PLATE Y1272
MP7 8930058170 SHIELD SPONGE (O)
MP9 8930059390 SHIELD SPONGE (Y)
MP10 8930083380 3331 AF SHEET (TC-30CG-AV)
*: Refer to "BOARD LAYOUTS" for the location.
Screw abbreviations
MECHANICAL PARTS
DESCRIPTION
DESCRIPTION
DESCRIPTION
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[MAIN-C UNIT]
REF ORDER
QTY.
NO. NO.
J1001* 6510014961 B2B-ZR-SM4-TF (LF) (SN)
1
J1002 6450000140 HSJ0807-01-010
J1003* 6510022891 B13B-ZR-SM4-TF (LF) (SN)
1
J1004* 6510027960 04-6294-040-000-800+
1
8
S1001* 2260003180 MINISMDC050F-2 CN <UDX>
2
2
W1 7030012290 RDS2T0R0
1
W2 8900011863 OPC-1195C
4
2
EP4 6910010280 HF70BB9.5X10.4X4.9
EP5 6910010280 HF70BB9.5X10.4X4.9
MP1* 8510019340 3179 VCO CASE Y1142
MP2 8510019350 3179 VCO COVER Y1143
MP3 8510015110 2602 M-PLATE Y660
QTY.
MP4 8930055841 2490 EARTH SPRING-1
MP5 8510014910 2601 FILTER CASE
1
MP6 8510020540 3331 B-SHIELD PLATE Y1272
1
MP9 8930059390 SHIELD SPONGE (Y)
1
MP10 8930083380 3331 AF SHEET (TC-30CG-AV)
1
MP12 8930072270 SHIELD SPONGE (BV)
1
[FRONT UNIT]
1
1
REF ORDER
NO. NO.
1
1
MP1 8210029140 3179 FRONT PANEL-2 <VNM>
1
MP3 8510019440 3179 SHIELD PLATE ASSEMBLYY1151
1
J1 6450002210 3017-8821 <KIN>
1
J2* 6510027960 04-6294-040-000-800+
1
1
DS11 5030003390 TAK-35877 FX-3331<ITAK>2
1
1
W1 8900010503 OPC-1046B-1 (P0.5N40L55)
1
1
EP2 8930059170 SRCN-2622-SP-N-W (SHJ)
1
1
MP5 8930081250 3179 KEYBOARD (A) (SC)
MP6 8610014010 KNOB N-386
MP8 8930059090 2622 LCD PLATE Y658
MP9 8210019350 2622 REFLECTOR
MP10 8930059100 2622 LCD FILTER
MP13 8810008761 PHBT M2 X 8 NI-ZC3
MP14 8930076110 INSULATION SHEET (ME)
QTY.
1
1
1
[ACCESSORIES]
1
REF ORDER
1
NO. NO.
1
MC1 (Optional) HM-152
1
(Optional) HM-152
(Optional) HM-152
1
(Optional) HM-152
1
(Optional) HM-152
(Optional) HM-152
1
1
W1 (Optional) OPC-1132A
1
W2 8900000731 OPC-049A
1
1
MP1 8010019151 2601 MOBIL BRACKET
1
MP3 8820000530 FLANGE BOLT M4 X 8 NI
1
MP4 8810000471 PH M5 X12 (+-) ZC3
1
MP5 8810005841 PHA M5 X20 ZC3
1
MP6 8850000150 FLAT WASHER M 5 NI BS
MP7 8850000391 S-WASHER M5 ZC3
MP8 8830000121 NUT M 5 ZC3
MP9 8950005110 2289 MIC HANGER Y468
MP11 8810004700 PHA M3 X16 SUS
8 - 1
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
[USA-01]
[EXP-01]
[CHN-01]
[USA-02]
[EXP-02]
[EXP-03]
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
1
1
1
1
1
1
1
1
1
1
4
4
4
4
4
4
1
2
