1 EVM Overview
The AMC1210 modular evaluation module (EVM) provides four modulator channels from the ADS1204 for
the AMC1210. Two are designated for resolver applications and two are designated for current
measurements. All interface modes of the AMC1210 are provided.
The new modular EVM form factor allows for direct evaluation of the AMC1210's performance and
operating characteristics. This EVM is compatible with the HPA-MCU Interface Board (SLAU106) from
Texas Instruments.
• Four modulator channels provided by ADS1204
• All AMC1210 interface modes available
• Direct operation with a variety of DSK and microcontroller platforms from Texas Instruments
• All four ADS1204 channels have an input range of 0 V to 5 V.
1.1 Analog Interface
The AMC1210 modular EVM is designed for easy interfacing to resolvers and current sensors. Connector
J05 is a 9-pole DSUB jack for easy connection to standard resolvers. To hold the floating resolver inputs
to a predefined common mode level, a 2.5-V voltage is added on the resolver inputs.
Signal
J05.1
J05.2
J05.3
J05.6
J05.7
J05.8
Shield
At the connectors J03 and J04, analog current sensor signals can be connected.
Signal
J03.1, J04.1
J03.2, J04.2
J03.3, J04.3
SLAU185 – August 2006
Submit Documentation Feedback
......................................................................................
......................................................................................
Description
IN1+ Positive sine wave input
IN1– Negative sine wave input
IN2 + Positive cosine wave input
PWM1 Positive carrier wave output
PWM2 Negative carrier wave output
IN2– Negative cosine wave input
PE Cable shield
Description
IN3+, IN4+ Positive current input signal
PE Cable shield
IN3–, IN4– Negative current input signal
