User Guide
EVALUATION BOARD CONFIGURATION

INPUT AND OUTPUT CONNECTIONS

Table 1 details the digital input and output connections, and
Table 1. Digital I/O Connections
Connection
SMA Connector
Terminal Connector
Load Capacitor
Termination Resistor
Table 2. M-LVDS Input and Output Connections
Connection A
SMA Connector J5
Termination Resistor

JUMPER CONNECTIONS

Table 3 details the jumper configurations.
Table 3. Jumper Configurations
Jumper Position Description
LK1 A Connects the RE pin of the ADN4693E-1 to VCC, which disables the receiver. This places the RO output into a high impedance state.
B Connects the RE pin of the ADN4693E-1 to the RE connection on the J1-4 screw terminal connector.
C Connects the RE pin of the ADN4693E-1 to GND, which enables the receiver.
LK2 A Connects the DE pin of the ADN4693E-1 to VCC, which enables the driver.
B Connects the DE pin of the ADN4693E-1 to the DE connection on the J1-4 screw terminal connector.
C Connects the DE pin of the ADN4693E-1 to GND, which disables the driver. This places the Y and Z outputs into a high impedance state.
D Connects the DE pin of the ADN4693E-1 to the RE pin of the ADN4693E-1. Set the state of both the DE and RE signals using the LK1 jumper.
analog.com
Table 2 details the M-LVDS input and output connections.
DI
J1
J1-4 via R2
None
R3
Receiver
B
J6
RT2
EVAL-ADN4693E-1
RO
J2
J1-4 via R1
C2 (not populated)
None
Transmitter
Y Z
J8 J9
RT1
Rev. 0 | 5 of 9
