System Q SEE850 Instructions Manual

2.8-12mm Eyeball with Motorised Lens
SEE850
SEE850
The SEE850 is a multi-format HD eyeball camera with Multi-Technology
outputs, a motorised lens and high powered IRs. It has TVI, AHD and CVI
mode selection plus a separate output for analogue (CVBS) use.
Special Features
In HD-TVI mode, the cameras have the Coaxitron Control facility for changing
the OSD menu specifi cations via the DVR or remote network connection or
via the camera. The motorised lens facility allows zoom and focus control to
be altered remotely without the need for site access.
This camera also has the NiteDevil menu feature for reducing shutter speed
for improving light capture at night.
*If you have fi tted cameras with IRs and have experienced condensation
issues or IR fl are, then this camera reduces these problems considerably
thanks to fl at dual front glass.
Mounting the Camera
The camera is for indoor or outdoor use and can be mounted on a wall,
ceiling or under a lintel.
First disconnect the base from the camera by unscrewing and
1
removing the securing plate.
2
Secure the base with screws using the 4 screw holes in the base
Adjust the eyeball camera and cover to ensure that the correct view
3
is achieved and refi t the securing plate.
The camera is IP66 rated and suitable for outdoor use.
01246 200 000
Features
• Motorised 2.8-12mm Lens
• Quad Technology
• 2 High Power IRs - Up to 35m Range
• True Day/Night IR Cut O Filter
• UTC and Co-axitron Control
• Weatherproof IP66 Rated Metal Body
• Extra Deep Base Option
• HD 1080P
• Switchable Video Output
• Gloss Black or Pure White Colour
Options
Speci cation
FUNCTION
Lens
Resolution
Lux
DayNight
IR LEDs
IR Range
Input Voltage
IP Rating
Backlight
Finish
Dimensions
Other Products To Consider
External HD
NiteDevil Camera
with 2.8-12mm
Varifocal Lens -
White
SEE820W
All speci cations are approximate. System Q Ltd reserves the right
to change any product speci cations or features without notice.
Whilst every e ort is made to ensure that these instructions are
complete and accurate, System Q Ltd cannot be held responsible
in any way for any losses, no matter how they arise, from errors
or omissions in these instructions, or the performance or
non-performance of the equipment that these instructions refer to.
This symbol on the products and/or accompanying
documents means that used electronic equipment
must not be mixed with general household waste.
For treatment, recovery and recycling please return
this unit to your trade supplier or local designated
WEE/CG0783SS collection point as de ned by your local council.
systemq.com
SPECIFICATION
2.8-12mm Motorised
1080P HD
0 with LEDs on
True Day/Night Filter
2
Up to 35m
12V DC
IP66
Backlight
Compensation
Gloss Black or Pure
White
120 Dia. x 90mm
External HD
NiteDevil Camera
with 2.8-12mm
Varifocal Lens -
Black
SEE820B
