Demonstration functional description (STM32F479I-EVAL and STM32F469I-DISCO)
Functional description
•
Start audio recorder module by touching the audio recorder icon as shown in
•
Press on the Record icon to start recording (see
•
Click on Stop icon to save the recorded data in USB disk or Click cancel to discard
them
•
Click on Play to listen to the last recorded data or Click on stop to return to the recorder
(Figure
90/111
(Figure 85)
86)

Figure 83. Audio recorder module startup

Figure 84. Start Audio recording

Figure 85. Stop Audio recording

DocID026161 Rev 4
Figure 84)
UM1743
Figure 83
